Bently Nevada 3500/05-01-01-01-00 3500/05 System Rack
Bently Nevada 3500/05-01-01-01-00 3500/05 System Rack
0.0
Points
Brand:Bently Nevada PLC Item No.:3500/05-01-01-01-00 Product Origin:USA Product Dimensions:Rack Size : 19-inch (14 module slots) Product Weight:4.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 3500/05-01-01-01-00 System Rack provides the essential mechanical foundation for a complete 3500 monitoring system.
Built for modern industrial reliability, this rack ensures precise mechanical alignment, clean internal organization, and secure module seating.
It enables users to deploy comprehensive monitoring systems for critical rotating machinery, offering a professional and durable platform trusted across high-demand industries.
With its modular capacity and proven construction, the rack ensures that 3500 Series hardware performs consistently and efficiently over the long term.
Technical Specifications
Parameter
Description
Product Type
3500/05 System Rack
Model
3500/05-01-01-01-00
Module Capacity
14 half-height modules
Rack Size
19-inch industry standard
Construction Material
Industrial-grade steel
Mounting Method
Horizontal 19-inch cabinet installation
System Compatibility
All Bently Nevada 3500 Series modules
Weight
4.5 kg
Recommended Related Models
Model
Description
3500/22
Vibration Monitoring Module
3500/23
Transient Data Module
3500/25
Proximity Module
3500/32
Speed & Keyphasor Module
3500/50
Power Supply Module
3500/62
Analog Output Module
3500/64
Digital Output Module
3500/94M
Touchscreen Display
3500/05 125565-01
Half-height Card Guide
3500/05 130768-01
Full-height Blank Cover Kit
Popular Related Models
Model
Description
3500/05-01-01-01-00
System Rack
3500/05-01-01-00-00-01
System Rack
3500/05-01-01-00-00-00
System Rack
3500/22
Vibration Monitor
3500/23
Monitoring Module
3500/32
Speed & Keyphasor Module
3500/94M
Touchscreen Display
3500/62
Analog Output
3500/64
Digital Output
3500/45
Overspeed Protection Module
Applications
The Bently Nevada 3500/05-01-01-01-00 System Rack is purpose-built for assembling complete 3500 Series machinery protection and condition monitoring systems.
It is widely applied in:
High-density vibration monitoring installations
Centralized housings for speed, temperature, and proximity modules
Large rotating equipment such as turbines, compressors, and generators
Industrial monitoring architectures that require dependable long-term performance
Plants where equipment diagnostics must be consolidated into a single rack platform
Advantages
Supports up to 14 half-height modules, providing scalability for complex systems
Conforms to the 19-inch industrial rack standard, ensuring effortless integration
Rigid mechanical structure maintains alignment and stability over years of operation
Streamlined layout simplifies wiring, backplane connection, and module servicing
Ventilation-friendly design promotes passive cooling for all installed electronics
Fully compatible with every 3500 Series monitoring module
Ideal for multi-channel protection architectures, enhancing system clarity and reliability
Engineered for demanding industrial environments, ensuring dependable uptime
FAQs
1. How many modules can fit into this rack?
This rack accommodates up to 14 half-height 3500 Series modules.
2. Does it support full-height modules?
No, only half-height modules are supported.
3. Is the rack aligned with standard cabinet dimensions?
Yes, it is designed for a 19-inch standard industrial rack frame.
4. Can modules be inserted while the system is energized?
No, modules should be installed or removed only when power is off.
5. How is cooling managed?
The rack uses open passive airflow, allowing natural ventilation around modules.
6. Is this rack vibration-resistant?
Yes, it is built to withstand typical industrial vibration exposure.
7. How are communication and power handled?
These are routed through the integrated rear backplane, not the rack frame itself.
8. Does it include any power supply hardware?
No, power supply modules must be installed separately in the rack slots.
9. Is it compatible with earlier 3500 Series module revisions?
Yes, all half-height 3500 Series modules can be installed regardless of revision.
10. What mounting orientation is recommended?
Horizontal installation in a 19-inch cabinet is recommended to maintain structural alignment.
