Woodward 5464‑013 Semi‑Insulated Input Driver Module for NetCon 5000 Industrial Control Systems
Woodward 5464‑013 Semi‑Insulated Input Driver Module for NetCon 5000 Industrial Control Systems
0.0
Points
Brand:Woodward Item No.:Woodward 5464‑013 Product Origin:USA Product Dimensions:191 × 25 × 235 mm Product Weight:0.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Woodward 5464‑013 is a semi‑insulated Input Driver Module tailored for industrial automation networks, particularly within the Woodward NetCon 5000 distributed control family. This module translates and conditions incoming field signals (such as sensor or RTD inputs) into controller‑ready logic levels, while its semi‑insulated design enhances noise immunity and reduces electrical interference. The robust build and fault‑indicator LED make it a practical choice for complex systems like turbine control, generator automation, and process plants where signal integrity and dependable performance are essential.
Technical Specifications
Specification
Details
Model
5464‑013
Module Type
Semi‑Insulated Input Driver Module
Manufacturer
Woodward (USA)
System Compatibility
NetCon 5000 distributed control architecture
Function
Converts and conditions field input signals for controller logic
Signal Support
Digital and analog/RTD input signaling (system dependent)
Fault Indicator
Red LED diagnostic indicator
Operating Temperature
−40 °C to +70 °C
Storage Temperature
−40 °C to +85 °C
Mounting
Panel or rack installation
Dimensions (L×W×H)
Approx. 191 × 25 × 235 mm
Weight
~0.5 kg (~450 g)
Status
Legacy; available new surplus/refurbished
Recommended Related Models
Woodward 5462‑750 Power Supply Module – Stable DC power for control racks
Woodward 5462‑757 Discrete Input Module – Digital signal interfacing
Woodward 5461‑644 Analog Output Module – Precise analog outputs
Woodward 5463‑581 Sensor Interface Module – Transducer and sensor signal conditioning
Popular Woodward Control Products
Woodward 5441 Series – Relay & discrete logic modules
Woodward 5461 Series – Analog & driver modules
Woodward 5462 Series – I/O and power supply modules
Woodward NetCon 5000 & MicroNet control platforms
Applications
This input driver module is best suited for industrial environments requiring accurate field signal conversion and noise‑resistant communication paths:
Turbine control and monitoring systems
Generator automation and protection racks
Distributed control systems (DCS) in power plants
Process automation in petrochemical and manufacturing facilities
Retrofit and legacy system maintenance
High‑noise industrial environments requiring signal isolation
By converting weak raw signals into usable logic levels, the 5464‑013 enables reliable integration with higher‑level controllers and enhances system diagnostics.
Key Advantages
Semi‑Insulated Design – Reduces ground loops and EMI for cleaner signal conditioning.
Fault‑Indicator LED – Instant visual feedback simplifies diagnostics.
NetCon 5000 Compatibility – Seamless integration into distributed control networks.
Rugged Industrial Build – Designed for harsh environments and continuous operation.
Compact Form Factor – Efficient panel or rack installation in control systems.
Technical FAQs
1. What is the primary role of the Woodward 5464‑013?
It’s an input driver module that conditions and translates field signals for use by a NetCon 5000 controller system.
2. What type of inputs does it handle?
It supports both digital and optional analog/RTD inputs for process and control signals.
3. How is the module installed?
It is mounted on a panel or rack within a control cabinet.
4. Does it provide any diagnostic indicators?
Yes — a red LED indicates fault conditions.
5. What temperature ranges can it operate in?
Operating temperatures range from −40 °C to +70 °C.
6. Is the 5464‑013 still manufactured?
The manufacturer has largely discontinued the module; it is often supplied as surplus or refurbished.
7. What is the approximate weight?
Approximately 0.5 kg.
8. Can it interface with legacy control systems?
Yes, it integrates with NetCon 5000 and compatible control architectures.
9. Why use a semi‑insulated input driver?
For improved noise immunity, signal reliability, and better electrical isolation.
10. What environments is it suited for?
Industrial automation, power generation, turbine control, and noisy electrical environments.
