The Honeywell 900G01-0202 is a high-precision analog input module designed for the ControlEdge HC900 platform, providing reliable acquisition of continuous process signals in industrial automation systems. It is used to interface with field instruments such as pressure transmitters, temperature sensors, flow meters, and level devices, converting analog signals into accurate digital data for control and monitoring.
Engineered for stability, accuracy, and noise immunity, this module plays a critical role in process industries where precise measurement and real-time data acquisition are essential for maintaining operational efficiency and safety.
Technical Specifications
| Specification | Details |
|---|---|
| Model | 900G01-0202 |
| Module Type | Analog Input Module |
| Platform | Honeywell ControlEdge HC900 |
| Input Channels | Typically 8–16 analog inputs |
| Input Signal Types | 4–20 mA, 0–10 V (model dependent) |
| Resolution | High-resolution A/D conversion |
| Accuracy | High precision for industrial process control |
| Isolation | Channel-to-channel and system isolation |
| Sampling Rate | Fast sampling for real-time monitoring |
| Communication | Backplane communication with CPU |
| Power Supply | Provided via HC900 base/rack |
| Operating Temperature | –20 °C to +60 °C |
| Mounting | Rack / DIN rail (HC900 system base) |
| Dimensions (H × W × D) | Approx. 120 × 40 × 110 mm |
| Weight | Approx. 0.30 kg |
| Status | Active industrial I/O module |
