The Honeywell 2MLQ-RY2B Relay Output Module is a high-density output solution designed for MasterLogic PLC platforms, delivering precise and reliable switching control across multiple field devices. With 16 relay output channels, it significantly enhances control capacity while maintaining stable performance in demanding industrial environments.

Engineered for flexibility and durability, this module allows seamless control of both AC and DC loads, making it suitable for complex automation systems where reliability and scalability are essential. Its relay isolation architecture ensures safe operation and protects sensitive PLC components from field-side disturbances.

Technical Specifications

Parameter	Specification
Model	2MLQ-RY2B
Module Type	Relay Output Module
Output Channels	16 Points
Output Type	Electromechanical Relay
Rated Load Voltage	DC 24V / AC 220–250V
Rated Load Current	2 A per channel
Minimum Load	5 V DC / 1 mA
Maximum Load	AC 250V / DC 125V
Isolation Method	Relay Isolation
Isolation Voltage	AC 560 V RMS
Switching Frequency	Up to 3,600 operations/hour
Mechanical Life	≥ 20 million operations
Leakage Current	0.1 mA (AC 220V, 60Hz)
Surge Protection	Varistor / CR absorber
Operating Temperature	-40°C to +85°C
Mounting Method	PLC Rack / Backplane
Dimensions (W × H × D)	26 × 98 × 97 mm
Weight	0.14 – 0.19 kg
