Brand:ABB Bailey Item No.:IMASO11 Product Origin:Sweden (SE) Product Dimensions:271.78 × 358.14 × 73.66 mm Product Weight:0.612 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB Bailey IMASO11 Analog Output Slave Module is engineered for high-demand industrial applications that require precise, reliable analog outputs. Designed for large-scale automation systems, IMASO11 converts digital control signals into stable analog outputs to operate valves, actuators, and motors with confidence. Its robust design, advanced diagnostics, and seamless compatibility with legacy and modern ABB systems make it ideal for industrial facilities seeking operational efficiency, minimized downtime, and optimized process control.
Technical Specifications
Parameter
Specification
Output Channels
16 analog outputs
Supported Signals
0–20 mA, 4–20 mA, ±10 V
Conversion Time
10 ms per channel
Output Isolation
Galvanic isolation per channel
Operating Temperature
-20°C to +70°C
Humidity
5–95% non-condensing
Power Supply
24 V DC ±10%
Weight
0.612 kg
Dimensions
271.78 × 358.14 × 73.66 mm
Recommended Related Models
Model
Description
IMASO12
High-capacity analog output module for large-scale control
IMASO15
Advanced diagnostic analog output module
IMASI30
Analog input module compatible with IMASO11
IMASO20
Precision multi-channel output module with extended range
Popular Related Models
Model
Description
IMASO11
Standard analog output slave module
IMASO14
Fast-response analog output module
IMASO18
Multi-channel analog output module for process control
IMASI22
Analog input module often paired with output modules
Applications
• Large-Scale Process Automation: Provides precise analog outputs for controlling industrial actuators, valves, and motors in high-demand environments.
• Energy & Utilities: Suitable for controlling equipment in power plants, substations, and renewable energy installations.
• Chemical, Pharmaceutical & Food Processing: Ensures accurate and reliable analog outputs for critical process control.
• Automation System Upgrades: Ideal for replacing older analog output modules in ABB Bailey and modern DCS systems.
• Research & Laboratory Facilities: Supports high-precision analog output for testing, R&D, and pilot-scale operations.
Key Advantages
• High-Precision Performance: Stable and reliable analog outputs guarantee smooth operation of controlled devices.
• Seamless Compatibility: Works with legacy Bailey systems and modern ABB DCS platforms, ensuring integration flexibility.
• Robust Industrial Design: Resistant to vibration, electrical noise, and temperature variations for uninterrupted operation.
• Advanced Diagnostics: Detects output anomalies, including short circuits and abnormal load conditions, supporting predictive maintenance.
• Quick Deployment: Easy configuration and commissioning minimize downtime and operational cost.
Technical FAQs
Q1: What types of analog output signals does IMASO11 support?
The module supports 0–20 mA, 4–20 mA, and ±10 V outputs, providing flexibility for various process applications.
Q2: How many channels are available on the IMASO11?
IMASO11 provides up to 16 analog output channels per module, suitable for large-scale control systems.
Q3: What is the response time for output signal updates?
The module updates each channel in approximately 10 ms, ensuring real-time process control.
Q4: Does the module provide electrical isolation for each channel?
Yes, each output channel is galvanically isolated to maintain signal integrity.
Q5: Is IMASO11 compatible with older ABB Bailey systems?
Yes, it supports backward compatibility while functioning seamlessly with modern ABB DCS platforms.
Q6: Can the module detect output faults automatically?
Yes, it provides detection of open circuits, short circuits, and abnormal load conditions.
Q7: What is the operational temperature range?
The module operates safely between -20°C and +70°C in industrial environments.
Q8: Can field calibration be performed on IMASO11?
Yes, field calibration is supported to minimize downtime and avoid module removal.
Q9: How does the module handle electrical noise?
It incorporates internal filtering and supports shielded cabling to maintain precise output signals.
Q10: Can IMASO11 be integrated into predictive maintenance systems?
Yes, diagnostic outputs can be fed into condition monitoring platforms to support predictive maintenance programs.
