ABB Bailey IMDSO03 6636037L1 Digital Output Slave Module
ABB Bailey IMDSO03 6636037L1 Digital Output Slave Module
0.0
Points
Brand:ABB Bailey Item No.:IMDSO03 Product Origin:Sweden (SE) Product Dimensions:160 x 110 x 25 mm Product Weight:0.567 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB Bailey IMDSO03 Digital Output Slave Module (6636037L1) delivers precise, reliable digital outputs for industrial automation systems. Designed for fast, accurate signal transmission, it controls actuators, relays, and process devices with confidence. Its compact yet robust construction, advanced diagnostic capabilities, and seamless compatibility with both legacy and modern ABB systems make IMDSO03 an ideal choice for system upgrades, new installations, and high-reliability process control applications.
Technical Specifications
Parameter
Specification
Output Channels
Up to 16 digital outputs
Output Type
DC digital outputs
Response Time
5–10 ms per channel
Channel Isolation
Galvanic isolation per channel
Operating Temperature
-20°C to +70°C
Humidity
5–95% non-condensing
Power Supply
24 V DC ±10%
Weight
0.567 kg
Dimensions (H × W × D)
160 × 110 × 25 mm
Recommended Related Models
Model
Description
IMDSO01
Digital output module with 8-channel configuration
IMDSO05
High-density digital output module for complex systems
IMDSO07
Digital output module with integrated diagnostics
IMCIS22
Control I/O module compatible with IMDSO03
Popular Related Models
Model
Description
IMDSO03
Standard digital output slave module
IMDSO02
Compact digital output module with fast response
IMDSO04
Multi-channel digital output module for process control
IMCIS23
Control I/O module paired for hybrid digital/analog systems
Applications
• Industrial Automation: Provides reliable digital output signals for controlling actuators, relays, and process devices.
• Power & Energy Systems: Ideal for power plants, substations, and renewable energy installations requiring precise digital outputs.
• Manufacturing & Process Industries: Ensures reliable operation of production equipment with accurate digital control.
• Automation System Upgrades: Perfect for replacing legacy digital output modules in ABB Bailey and modern DCS architectures.
• Testing & R&D Facilities: Supports precise digital output for experimental setups and laboratory automation.
Key Advantages
• High-Precision Digital Outputs: Ensures stable and accurate signal delivery for controlled devices.
• Seamless Integration: Fully compatible with legacy Bailey networks and modern ABB DCS platforms.
• Robust Construction: Resistant to industrial vibration, electrical noise, and temperature variations.
• Advanced Diagnostics: Detects output faults including short circuits and abnormal load conditions.
• Quick Setup & Commissioning: Simplified configuration saves installation time and reduces operational downtime.
