Designed for demanding industrial environments, the Schneider Electric 140AVI03000 analog input module brings together flexibility and measurement accuracy in one compact solution. As part of the Modicon Quantum platform, it is engineered to handle a wide variety of analog signals with exceptional precision, making it a dependable choice for engineers working on complex process control systems.

Its multirange capability allows seamless integration of both voltage and current inputs, reducing the need for additional signal conditioning hardware. This not only simplifies system architecture but also enhances overall efficiency in large-scale automation deployments.

Technical Specifications Overview

Parameter	Specification
Module Type	Analog Input Module
Platform	Modicon Quantum
Number of Channels	8 Differential Inputs
Supported Input Ranges	0–5 V, 0–10 V, ±5 V, ±10 V, 0–20 mA, ±20 mA
Resolution	16-bit
Accuracy	±0.03% to ±0.05% of Full Scale
Conversion Time	10 ms
Input Impedance	250 MΩ (Voltage Inputs)
Electrical Isolation	500 Vrms / 750 V DC
Backplane Current Consumption	280 mA
Power Dissipation	Approx. 2.2 W
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 85°C
Dimensions (H×W×D)	40 × 110 × 250 mm
Weight	Approx. 0.42 kg

Suggested Companion Modules

140ACI03000 Analog Input Module
140ACO02000 Analog Output Module
140CPU67160 Quantum Processor
140CRA93200 Ethernet Remote I/O Adapter
140XBP01600 Backplane

Commonly Selected Schneider Modules

BMXP342020 Processor Module
BMXAMI0810 Analog Input Module
BMXDDI1602 Digital Input Module
BMXDDO1602 Digital Output Module
BMXNOC0401 Ethernet Communication Module

Application Scenarios

The 140AVI03000 is widely utilized in industries where signal accuracy and system reliability are critical:

Continuous process industries such as oil & gas and chemicals
Power plants and energy management systems
Water treatment and environmental monitoring
Industrial manufacturing and batch processing
Infrastructure automation systems

Application Scenarios

The 140AVI03000 is widely utilized in industries where signal accuracy and system reliability are critical:

Continuous process industries such as oil & gas and chemicals
Power plants and energy management systems
Water treatment and environmental monitoring
Industrial manufacturing and batch processing
Infrastructure automation systems

Core Advantages

What makes the 140AVI03000 particularly attractive is its combination of versatility and precision. Engineers benefit from its ability to accept multiple signal types without additional converters, which significantly reduces engineering time and system cost.

Its high-resolution conversion ensures that even the smallest signal variations are captured accurately, improving control performance. Additionally, built-in diagnostics enhance operational transparency, allowing maintenance teams to identify issues quickly and minimize downtime.

Technical FAQs

How many analog inputs are available?
The module provides 8 differential analog input channels.
Can it process both voltage and current signals?
Yes, it supports a wide range of voltage and current inputs.
What level of accuracy can be expected?
Accuracy ranges between ±0.03% and ±0.05% of full scale.
Is external power required for operation?
No, it operates using power supplied via the Quantum backplane.
How fast is the signal conversion?
The module processes data with a typical update time of 10 ms.
Does it support fault detection?
Yes, it includes diagnostics such as overrange and wiring fault detection.
Is it suitable for noisy industrial environments?
Absolutely, its differential inputs and isolation provide strong noise immunity.
What systems is it compatible with?
It is designed specifically for Modicon Quantum automation systems.
How is the module installed?
It mounts directly onto a Quantum backplane rack.
What is the main benefit of using this module?
Its multirange capability and high precision make it ideal for complex, high-performance control systems.
