Honeywell 05701-A-0302 Pressure Transducer

Introduction

The Honeywell 05701-A-0302 is an advanced Pressure Transducer designed to deliver high-precision pressure measurements in industrial environments. This transducer is engineered to meet the needs of a wide range of applications where accurate and reliable pressure data is essential for monitoring and control processes. It is ideal for use in industries such as oil & gas, chemical processing, HVAC, and automotive, providing superior performance even in harsh conditions.

With its robust construction, the 05701-A-0302 offers excellent linear accuracy, a wide measuring range, and extended operational lifespan. It is capable of delivering analog or digital outputs depending on system requirements, and features advanced protection mechanisms to ensure reliable operation under extreme environmental conditions.

Technical Specifications

Specification	Details
Model	05701-A-0302
Module Type	Pressure Transducer
Measuring Range	0 to 5000 psi (varies by model configuration)
Output Signal	4-20 mA, 0-5 V, 0-10 V (depending on configuration)
Accuracy	±0.25% of Full Scale
Size (W x H x D)	35 x 50 x 20 mm
Weight	0.3 kg
Operating Temperature	-40°C to +85°C
Pressure Type	Gage, Absolute, Differential
Protection Features	Overpressure protection, Reverse polarity protection
Certifications	CE, RoHS, UL

Recommended Related Models

Model	Module Type	Key Feature
Honeywell 05701-A-0283	Pressure Transducer	Ideal for high-accuracy pressure measurement
Honeywell 132501	Differential Pressure Transducer	Suitable for differential pressure applications
Honeywell 06700-A-0215	Pressure Transducer	Designed for harsh industrial environments with digital output

Popular Honeywell Models

Model	Module Type	Key Feature
Honeywell 134220-02	Pressure Transducer	Compact and high-performance solution for industrial pressure measurement
Honeywell 120165	Temperature Transducer	Ideal for temperature monitoring in critical systems
Honeywell 06701	Pressure Transducer	Suitable for extreme high-temperature and high-pressure environments

Applications

Industrial Automation: The 05701-A-0302 is widely used in industrial control systems where precise and reliable pressure data is required for process monitoring and control, such as in chemical plants, oil refineries, and power plants.
Oil & Gas: The 05701-A-0302 is perfect for downhole pressure measurements in oil & gas fields, ensuring real-time monitoring of well pressure and enhancing operational safety and efficiency.
HVAC Systems: In HVAC applications, it helps in maintaining optimal pressure conditions within air conditioning and refrigeration systems, ensuring energy efficiency and stable performance.
Automotive Industry: The 05701-A-0302 is commonly used in automotive pressure monitoring systems, including engine pressure, fuel pressure, and braking systems.
Manufacturing: In manufacturing automation, the module is used to measure hydraulic pressure in pressing, clamping, and forming operations, ensuring consistency and quality in production.

Advantages

High Precision: The 05701-A-0302 provides a ±0.25% accuracy across its full scale, ensuring precise and reliable pressure measurements, even under fluctuating conditions.
Wide Pressure Range: It supports a pressure range up to 5000 psi, offering flexibility for both low and high-pressure applications.
Rugged Design: The 05701-A-0302 is designed to endure tough industrial conditions, with overpressure protection and reverse polarity protection features to prevent damage in case of faults.
Flexible Output: The module supports multiple output signals, including 4-20 mA, 0-5 V, and 0-10 V, making it compatible with a variety of control systems and allowing easy integration into existing setups.
Compact and Lightweight: With a size of 35 x 50 x 20 mm and weighing just 0.3 kg, this transducer is compact and easy to install in space-constrained industrial environments.

Technical FAQs

What is the measuring range of the Honeywell 05701-A-0302?
The 05701-A-0302 has a measuring range from 0 to 5000 psi, with various configurations available.
What output signals does the 05701-A-0302 support?
It supports 4-20 mA, 0-5 V, and 0-10 V output signals, providing flexibility for different system integrations.
What is the accuracy of the Honeywell 05701-A-0302?
The module offers ±0.25% full-scale accuracy for precise pressure readings.
What are the dimensions of the Honeywell 05701-A-0302?
The module has a size of 35 x 50 x 20 mm.
What is the weight of the Honeywell 05701-A-0302?
The 05701-A-0302 weighs 0.3 kg.
What is the operating temperature range for the Honeywell 05701-A-0302?
It operates within a temperature range of -40°C to +85°C.
What protection features are included in the 05701-A-0302?
The transducer includes overpressure protection and reverse polarity protection for enhanced durability.
Can the 05701-A-0302 be used in hazardous environments?
Yes, the 05701-A-0302 is built to withstand harsh environments, making it ideal for use in industries like oil & gas, chemical processing, and automotive.
What certifications does the 05701-A-0302 have?
The module is CE, RoHS, and UL certified, meeting global industrial standards.
What industries can benefit from the Honeywell 05701-A-0302?
Industries such as oil & gas, chemical processing, automotive, HVAC systems, and manufacturing can benefit from the reliable pressure measurements provided by this transducer.
