The Schneider Electric 140NOE77110 is a high-performance Ethernet TCP/IP communication module for the Modicon Quantum PLC platform, engineered to deliver fast, reliable, and scalable industrial networking.
Featuring both fiber optic and copper (RJ45) interfaces, this module enables flexible integration into diverse industrial network topologies. With support for Modbus TCP/IP, SNMP, and web-based diagnostics, it is ideal for modernizing legacy systems while maintaining robust communication performance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Ethernet Network TCP/IP Communication Module |
| Platform | Modicon Quantum |
| Communication Protocols | Modbus TCP/IP, SNMP |
| Ethernet Interfaces | RJ45 (10/100BASE-TX) + MT/RJ (100BASE-FX fiber optic) |
| Transmission Rate | 10 / 100 Mbit/s |
| Web Server | Class C20 (Transparent Ready, FactoryCast) |
| Communication Services | Modbus TCP messaging, SNMP network management |
| Redundancy | Hot standby redundant architecture |
| Diagnostics | Full LED status indicators + embedded web tools |
| Bus Current Requirement | ~750 mA @ 5 V DC |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Dimensions (H × W × D) | 260 × 120 × 50 mm |
| Weight | Approx. 0.35 – 0.50 kg |
