The Schneider Electric 140SHS94500 is a high‑capacity DC power supply module designed for the Modicon Quantum PLC automation platform. Engineered to deliver robust and reliable 24 V DC power to the Quantum rack and attached I/O modules, this power supply ensures stable operation in demanding industrial environments.
Its high current output and industrial‑grade construction make it ideal for medium to large PLC systems that require dependable power delivery with built‑in protection against overload and short‑circuit conditions.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | DC Power Supply Module |
| Platform | Modicon Quantum |
| Output Voltage | 24 V DC |
| Current Rating | 45 A |
| Power Output | Approx. 1080 W |
| Voltage Tolerance | ± 5 % |
| Output Ripples | < 1 % |
| Protection | Overload, short‑circuit, overvoltage protection |
| Display / Indicators | LED indicators for OK / Fault status |
| Cooling | Convection / Fan‑assisted (depending on configuration) |
| Mounting | Quantum backplane / DIN mount |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to 85 °C |
| Dimensions (H × W × D) | 205 × 110 × 100 mm (typical Quantum power module size) |
| Weight | Approx. 2.5 kg |
| Certifications | CE and industrial compliance |
