The Schneider 140XCP90000 Advanced Communication Module is designed to provide robust, high-speed data communication for industrial automation systems. Optimized for PLC network integration and distributed I/O applications, this module ensures real-time process control, high reliability, and seamless connectivity across complex industrial operations. Built with durability and compatibility in mind, it simplifies system integration while maximizing operational efficiency.

Technical Specifications

Feature	Specification
Module Type	Communication Module
Model Number	140XCP90000
Dimensions (L × W × H)	150 mm × 45 mm × 120 mm
Weight	0.60 kg
Power Supply	24 V DC
Network Compatibility	Modbus RTU, Profibus DP, Ethernet/IP
Operating Temperature	0°C to 60°C
Storage Temperature	-20°C to 70°C
Certifications	CE, UL, RoHS
Mounting	DIN Rail / Panel Mountable

Recommended Related Models

Schneider 140XBP01600 – High-speed I/O expansion module
Schneider 140XBP01000 – Remote communication interface
Schneider 140NOL91800C – Digital output module for advanced automation systems

Popular Schneider Models

Schneider TSX P57C024M – PLC communication module for industrial networks
Schneider TSXPBY100 – Fieldbus interface for distributed I/O
Schneider TSXPCX1031-C – Industrial control networking module

Applications

High-speed PLC and industrial automation networks
Real-time communication between Schneider PLCs and distributed I/O devices
Integration with SCADA and HMI platforms for process monitoring and control
Process automation in manufacturing, energy, and utilities sectors

Advantages

Exceptional Reliability: Designed for continuous operation in demanding industrial environments
Seamless Integration: Fully compatible with Schneider and third-party PLC systems
Compact Yet Powerful: Saves panel space while delivering comprehensive communication capabilities
High-Speed Data Transfer: Ensures accurate, real-time monitoring and control
Industry Certified: CE, UL, and RoHS compliance guarantees trusted deployment

Technical FAQs

Which networks are supported by the 140XCP90000?
Modbus RTU, Profibus DP, and Ethernet/IP.
Can this module be mounted on a DIN rail?
Yes, supports both DIN rail and panel mounting.
What is the operating temperature range?
0°C to 60°C.
Is it compatible with Schneider PLCs?
Yes, fully compatible with most Schneider automation systems.
What are the module’s dimensions and weight?
150 mm × 45 mm × 120 mm; 0.60 kg.
What power supply does it require?
24 V DC.
Can it operate in harsh industrial environments?
Yes, although specific hazardous area certifications should be verified.
Does it support remote monitoring?
Yes, it allows real-time communication and remote supervision.
Which certifications does the module hold?
CE, UL, RoHS.
How is data reliability ensured?
Advanced error-checking protocols and industrial communication standards guarantee accurate and secure data transmission.
