The Schneider 170XTS00501 Touchscreen Operator Panel provides an intuitive human-machine interface (HMI) for industrial automation systems. Designed for seamless integration with Schneider PLCs and modular I/O systems, this module allows operators to monitor, control, and visualize process data in real-time. With a responsive touchscreen interface, customizable displays, and robust connectivity, it enhances operational efficiency, reduces errors, and improves decision-making in manufacturing, energy, and utility applications.
Technical Specifications
| Feature | Specification |
|---|---|
| Module Type | Touchscreen Operator Panel |
| Model Number | 170XTS00501 |
| Display | 5-inch TFT color touchscreen |
| Dimensions (L × W × H) | 165 mm × 125 mm × 45 mm |
| Weight | 0.95 kg |
| Communication Protocols | Modbus RTU, Modbus TCP, Ethernet/IP, Profibus DP |
| Input/Output | Integrated digital and analog I/O support via PLC |
| Resolution | 800 × 480 pixels |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Mounting | Panel Mountable / DIN Rail Adapter Optional |
| Certifications | CE, UL, RoHS |
