The Schneider 490NAC0100 AC Drive Module is designed to deliver high-efficiency, precise control of AC motors in industrial automation applications. Ideal for manufacturing, HVAC, and process control systems, this module ensures reliable motor performance, energy savings, and flexible integration with Schneider motor control platforms. With advanced control algorithms and robust industrial design, it helps optimize production processes while reducing operational costs.
Technical Specifications
| Feature | Specification |
|---|---|
| Module Type | AC Drive / Motor Controller |
| Model Number | 490NAC0100 |
| Dimensions (L × W × H) | 210 mm × 95 mm × 165 mm |
| Weight | 2.3 kg |
| Motor Power Range | 0.75 kW – 1.5 kW |
| Voltage | 200–240 V AC, 1-phase |
| Output Frequency | 0–400 Hz |
| Control Modes | V/f Control, Sensorless Vector Control |
| Communication Protocols | Modbus RTU, CANopen, Ethernet/IP optional |
| Protection Features | Overload, Short Circuit, Overvoltage, Undervoltage |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 70°C |
| Mounting | Wall mountable / Panel mountable |
| Certifications | CE, UL, RoHS |
