The Schneider ATV212HD11N4 Variable Frequency Drive (VFD) is engineered for energy-efficient motor control in industrial and HVAC applications. As part of the proven Altivar 212 series, it delivers reliable performance, precise speed regulation, and seamless integration with automation systems. Designed specifically for pumps, fans, and compressors, this drive helps reduce energy consumption, extend equipment lifespan, and ensure smooth operation in demanding environments.
Technical Specifications
| Feature | Specification |
|---|---|
| Module Type | Variable Frequency Drive (VFD) |
| Model Number | ATV212HD11N4 |
| Dimensions (L × W × H) | 240 mm × 140 mm × 180 mm |
| Weight | 4.2 kg |
| Motor Power | 11 kW / 15 HP |
| Input Voltage | 380–480 V AC, 3-phase |
| Input Frequency | 50–60 Hz |
| Output Frequency | 0.5–200 Hz |
| Rated Current | 22.5 A |
| Control Modes | V/f Control, Energy-saving optimized control |
| Communication Protocols | Modbus, BACnet, LonWorks, Metasys N2 |
| Protection Rating | IP21 |
| EMC Filter | Built-in Class C2 |
| Operating Temperature | -10°C to 50°C |
| Mounting | Wall / Panel Mountable |
| Certifications | CE, UL, RoHS |
