Schneider ATV320U07N4B Altivar Machine ATV320 Series 0.75kW Book-Style Variable Speed Drive for Compact Industrial Automation
Schneider ATV320U07N4B Altivar Machine ATV320 Series 0.75kW Book-Style Variable Speed Drive for Compact Industrial Automation
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV320U07N4B Product Origin: France Product Dimensions:325 × 45 × 245 mm Product Weight:2.1 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV320U07N4B is a compact yet highly capable variable speed drive from the Altivar Machine ATV320 series, specifically engineered for modern machine builders and compact control cabinets. Featuring a slim “book-style” design, it maximizes panel space while delivering reliable motor control performance for small-scale industrial applications.
Despite its compact size, this drive integrates advanced vector control technology, ensuring smooth motor operation, precise torque delivery, and energy-efficient performance. It is an excellent choice for applications where space optimization and reliability are equally critical.
Technical Specifications
Parameter
Specification
Model
ATV320U07N4B
Product Type
Variable Speed Drive (VFD)
Series
Altivar Machine ATV320
Rated Power
0.75 kW
Input Voltage
380–500 V AC (3-phase)
Rated Output Current
2.3 A
Output Frequency
Up to 500 Hz
Control Method
Sensorless Vector Control
Communication
Modbus, CANopen (expandable via option cards)
Form Factor
Book-style (compact)
Protection Rating
IP20
Operating Temperature
Up to 60°C (with derating)
Dimensions (H × W × D)
325 × 45 × 245 mm
Weight
2.1 kg
Mounting Type
Cabinet / Panel Mount
Recommended Related Models
ATV320U04N4B – 0.4 kW compact drive for lighter loads
ATV320U15N4B – 1.5 kW version for increased capacity
ATV320U22N4B – 2.2 kW model for medium applications
ATV320D07N4C – Compact chassis version with enhanced features
ATV340U07N4 – Advanced drive for high-dynamic control
Popular Schneider Electric Models
Altivar 320 Series Drives
Altivar 340 Performance Drives
Altivar 630 Process Drives
Modicon M221 PLC
Modicon M241 Controller
Applications
The ATV320U07N4B is designed for compact and precision-driven applications:
Small conveyor systems
Packaging and labeling machines
Light-duty material handling
Pumps and ventilation systems
Textile and ceramic machinery
OEM compact equipment
Advantages
Ultra-Compact Design: Book-style format significantly reduces cabinet space requirements
Reliable Motor Control: Ensures stable speed and torque even at low speeds
Energy Efficient: Optimizes motor performance and reduces power consumption
Flexible Integration: Supports multiple communication options via expansion modules
Robust Construction: Coated circuit boards enhance durability in harsh environments
High Temperature Capability: Operates up to 60°C without additional cooling
Technical FAQs
1. What motor size is supported?
It supports motors up to 0.75 kW (1 HP).
2. What is the input voltage range?
380–500 V AC, three-phase.
3. What makes the “book-style” design beneficial?
It allows vertical installation, saving panel space.
4. Does it support communication protocols?
Yes, Modbus and CANopen are standard, with optional expansions.
5. Can it operate in harsh environments?
Yes, coated boards and robust design improve reliability.
6. What type of motors can be controlled?
Both synchronous and asynchronous motors are supported.
7. Is additional cooling required?
No, it can operate at high temperatures without extra cooling in many cases.
8. What is the output current rating?
Approximately 2.3 A.
9. Is it suitable for OEM applications?
Yes, it is specifically designed for machine builders.
10. What industries commonly use this model?
Packaging, automation, light manufacturing, and machinery sectors.
