The Schneider ATV610U07N4 is a reliable and energy-efficient variable speed drive from the Easy Altivar 610 series, specifically engineered for fluid management and process automation applications. Designed with simplicity and performance in mind, this drive is ideal for controlling pumps, fans, and compressors in industries where stable operation and energy savings are essential.
With its plug-and-play functionality, integrated EMC filter, and user-friendly interface, the ATV610U07N4 allows quick commissioning and seamless operation. It is widely trusted in water treatment, HVAC, and industrial process systems where efficiency and durability are critical.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV610U07N4 |
| Product Type | Variable Speed Drive (VFD) |
| Series | Easy Altivar 610 |
| Rated Power | 0.75 kW (1 HP) |
| Input Voltage | 380–460 V AC (3-phase) |
| Output Frequency | 0.1 – 500 Hz |
| Control Method | V/F, Optimized Torque Control |
| Communication | Modbus (built-in) |
| Digital Inputs | 6 |
| Analog Inputs | 3 |
| Analog Outputs | 2 |
| Protection Rating | IP20 |
| EMC Filter | Integrated (IEC/EN 61800-3 C3) |
| Operating Temperature | -15°C to +45°C |
| Dimensions (H × W × D) | 297 × 145 × 203 mm |
| Weight | 2.4 – 4.2 kg (depending on configuration) |
| Mounting Type | Cabinet / Wall Mount |
Recommended Related Models
- ATV610U15N4 – 1.5 kW model for higher load requirements
- ATV610U22N4 – 2.2 kW version for medium-duty systems
- ATV610D18N4 – 18.5 kW high-power process drive
- ATV630U07N4 – Advanced process drive alternative
- ATV320U07N4C – Compact machine drive for OEM applications
