Schneider ATV610U22N4 Easy Altivar 610 Series 2.2kW Variable Frequency Drive for Energy-Efficient Pump, Fan and Process Automation Systems
Schneider ATV610U22N4 Easy Altivar 610 Series 2.2kW Variable Frequency Drive for Energy-Efficient Pump, Fan and Process Automation Systems
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV610U22N4 Product Origin:France Product Dimensions:297 × 145 × 203 mm Product Weight:2.4 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV610U22N4 is a process-optimized variable frequency drive from the Easy Altivar 610 series, specifically designed for fluid management applications such as pumps, fans, and compressors. It combines reliable performance with energy efficiency, making it an ideal solution for industries that require continuous operation and optimized energy consumption.
With its robust industrial design, integrated EMC filter, and simple commissioning process, this drive ensures stable motor control and reduced downtime. It is widely adopted in water treatment, HVAC systems, and general process automation where reliability and efficiency are critical.
Technical Specifications
Parameter
Specification
Model
ATV610U22N4
Product Type
Variable Speed Drive (VFD)
Series
Easy Altivar 610
Rated Power
2.2 kW (3 HP)
Input Voltage
380–460 V AC (3-phase)
Rated Output Current
5.6 A (normal duty)
Output Frequency
0.1 – 500 Hz
Control Method
V/F, Optimized Torque Control
Communication
Modbus RTU (built-in)
Digital Inputs
6
Analog Inputs
3
Analog Outputs
2
Protection Rating
IP20
EMC Filter
Integrated (IEC/EN 61800-3 C3)
Cooling Method
Forced convection
Operating Temperature
-15°C to +45°C
Dimensions (H × W × D)
297 × 145 × 203 mm
Weight
Approx. 2.4 kg
Mounting Type
Wall / Cabinet Mount
Recommended Related Models
ATV610U15N4 – 1.5 kW version for smaller systems
ATV610U30N4 – 3 kW model for higher load demands
ATV610D18N4 – 18.5 kW high-power process drive
ATV630U22N4 – Advanced process drive alternative
ATV320U22N4C – Machine automation drive for OEM applications
Popular Schneider Electric Models
Altivar 610 Process Drives
Altivar 630 Process Drives
Altivar 320 Machine Drives
Modicon M221 / M241 PLC
TeSys Motor Control Series
Applications
The ATV610U22N4 is purpose-built for process-driven environments where energy efficiency and stability are essential:
Water supply and wastewater treatment systems
HVAC systems (fans, air handling units)
Pumping and fluid transfer applications
Industrial ventilation and compressors
Conveyor systems in process industries
Oil & gas auxiliary systems
Advantages
Process-Optimized Performance: Specifically designed for pumps and fans with optimized torque control
Energy Efficiency: Can significantly reduce energy consumption in variable torque applications
Reliable Continuous Operation: Built for 24/7 industrial environments
Integrated EMC Filter: Ensures compliance and reduces electrical interference
User-Friendly Setup: Supports keypad or PC configuration for quick commissioning
Flexible Communication: Built-in Modbus for seamless system integration
Technical FAQs
1. What motor capacity does this drive support?
It supports motors up to 2.2 kW (3 HP).
2. What is the input voltage range?
380–460 V AC, three-phase supply.
3. What applications is it designed for?
Primarily pumps, fans, compressors, and conveyors.
4. What is the output frequency range?
0.1 Hz to 500 Hz.
5. Does it support communication protocols?
Yes, Modbus RTU is built-in.
6. Is an EMC filter included?
Yes, an integrated EMC filter is standard.
7. Can it operate continuously?
Yes, it is designed for continuous industrial operation.
8. What is the protection rating?
IP20, suitable for installation inside control cabinets.
9. What type of motors are supported?
It is designed for three-phase asynchronous motors.
10. What makes ATV610 different from ATV320 series?
ATV610 is optimized for process applications (pumps/fans), while ATV320 is focused on machine automation.
