Schneider ATV630D11N4 Altivar Process ATV630 Series 11kW High-Efficiency Variable Speed Drive for Pumps, Fans and Industrial Process Automation
Schneider ATV630D11N4 Altivar Process ATV630 Series 11kW High-Efficiency Variable Speed Drive for Pumps, Fans and Industrial Process Automation
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV630D11N4 Product Origin:France Product Dimensions:409 × 171 × 233 mm Product Weight:7.7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV630D11N4 is a next-generation variable speed drive from the Altivar Process ATV630 series, designed specifically for process and utility applications. With its intelligent energy management features and advanced connectivity, it delivers optimized motor control for pumps, fans, compressors, and fluid handling systems.
Compared to legacy Altivar 61 models, this drive integrates modern diagnostics, embedded energy monitoring, and Ethernet-based communication, making it a future-ready solution for smart industrial automation. It is widely used in water treatment, HVAC, oil & gas, and manufacturing environments where efficiency and reliability are critical.
Technical Specifications
Parameter
Specification
Model
ATV630D11N4
Product Type
Variable Speed Drive (VFD)
Series
Altivar Process ATV630
Rated Power
11 kW (Normal Duty) / 7.5 kW (Heavy Duty)
Input Voltage
380–480 V AC (3-phase)
Rated Output Current
23.5 A (ND) / 16.5 A (HD)
Output Frequency
0.1 – 500 Hz
Control Method
V/F, Advanced Process Control
Communication
Modbus TCP, Modbus Serial, Ethernet
Safety
Safe Torque Off (STO), SIL 3
EMC Filter
Integrated (C2/C3 compliant)
Cooling Method
Forced convection
Protection Rating
IP21 (typical)
Operating Temperature
-15°C to +60°C
Dimensions (H × W × D)
409 × 171 × 233 mm
Weight
Approx. 7.7 kg
Mounting Type
Wall / Panel Mount
Key data verified from industrial product specifications
Recommended Related Models
ATV630D15N4 – 15 kW version for higher load requirements
ATV630D07N4 – 7.5 kW model for smaller systems
ATV610U11N4 – Cost-optimized process drive alternative
ATV930D11N4 – High-end process drive with advanced analytics
ATV320D11N4C – Machine automation alternative
Popular Schneider Electric Models
Altivar 630 Process Drives
Altivar 610 Series Drives
Altivar 320 Machine Drives
Modicon M580 PLC
EcoStruxure Automation Platform
Applications
The ATV630D11N4 is purpose-built for process industries requiring intelligent motor control and energy optimization:
Water and wastewater treatment plants
HVAC systems (fans, pumps, air handling units)
Oil & gas processing systems
Mining and mineral processing
Food & beverage production lines
Industrial pumping and fluid transfer systems
Advantages
Energy Optimization: Built-in energy monitoring and “Stop & Go” function reduce consumption significantly
Advanced Connectivity: Native Ethernet and Modbus TCP enable seamless integration into modern networks
Process Intelligence: Embedded diagnostics and asset monitoring improve uptime and maintenance efficiency
High Safety Standard: SIL3-rated Safe Torque Off enhances operational safety
Flexible Motor Control: Supports both asynchronous and synchronous motors
Compact Yet Powerful: 11 kW performance in a relatively compact (~7.7 kg) design
Technical FAQs
1. What motor capacity does this drive support?
It supports up to 11 kW (normal duty) and 7.5 kW (heavy duty).
2. What is the input voltage range?
380–480 V AC, three-phase supply.
3. What communication protocols are available?
Modbus TCP, Modbus serial, and Ethernet are supported.
4. Does it include safety features?
Yes, it includes Safe Torque Off (STO) rated SIL 3.
5. What is the maximum output frequency?
Up to 500 Hz depending on configuration.
6. Can it handle different motor types?
Yes, both asynchronous and synchronous motors are supported.
7. What is the cooling method?
Forced convection cooling ensures stable operation.
8. Does it include an EMC filter?
Yes, integrated EMC filters compliant with C2/C3 standards.
9. What industries typically use this model?
Water treatment, HVAC, oil & gas, mining, and general process industries.
10. How does it compare to ATV61 series?
ATV630 offers modern Ethernet connectivity, energy analytics, and enhanced diagnostics, making it a direct upgrade over ATV61.
