Brand:Schneider PLC Item No.:Schneider ATV630D22N4 Product Origin:France Product Dimensions:546 × 211 × 232 mm Product Weight:14.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV630D22N4 is a high-performance variable speed drive from the Altivar Process ATV630 series, designed to deliver intelligent motor control for demanding process applications. With a rated power of 22kW (30HP), it is ideal for pumps, fans, compressors, and fluid handling systems where energy efficiency, connectivity, and reliability are essential.
As a modern replacement for legacy Altivar 61 drives, this model integrates advanced diagnostics, embedded energy monitoring, and Ethernet-based communication—making it a key component in Industry 4.0-ready automation systems.
Technical Specifications
Parameter
Specification
Model
ATV630D22N4
Product Type
Variable Speed Drive (VFD)
Series
Altivar Process ATV630
Rated Power
22 kW (Normal Duty) / 18.5 kW (Heavy Duty)
Input Voltage
380–480 V AC (3-phase)
Rated Output Current
46.3 A (ND) / ~39 A (HD)
Output Frequency
0.1 – 500 Hz (up to ~599 Hz configurable)
Control Method
V/F, Vector Control, Process Control
Communication
Ethernet, Modbus TCP, Modbus RTU, RS-485
Safety
Safe Torque Off (STO), SIL 3
EMC Filter
Integrated (C2/C3 compliant)
Protection Rating
IP21 (UL Type 1)
Cooling Method
Forced convection
Operating Temperature
-15°C to +60°C
Dimensions (H × W × D)
546 × 211 × 232 mm
Weight
Approx. 14.3 kg
Mounting Type
Wall / Panel Mount
Recommended Related Models
ATV630D15N4 – 15 kW version for medium-duty systems
ATV630D18N4 – 18.5 kW model for higher performance
ATV610U22N4 – Cost-optimized process drive alternative
ATV930D22N4 – High-end drive with advanced analytics
ATV320D22N4C – Machine automation drive for OEM applications
Popular Schneider Electric Models
Altivar 630 Process Drives
Altivar 610 Series Drives
Altivar 320 Machine Drives
Modicon M580 PLC
EcoStruxure Automation Platform
Applications
The ATV630D22N4 is engineered for intelligent process automation and energy optimization:
Water and wastewater treatment plants
HVAC systems (fans, pumps, chillers)
Oil & gas processing systems
Mining and mineral processing
Food & beverage production lines
Industrial pumping and fluid transfer systems
Advantages
Energy Optimization: “Stop & Go” function can reduce energy consumption by up to 30% in standby conditions
Smart Connectivity: Built-in Ethernet and Modbus TCP enable seamless integration into SCADA/DCS systems
Process Intelligence: Embedded diagnostics and monitoring improve uptime and predictive maintenance
High Safety Standard: SIL3-rated Safe Torque Off enhances operational safety
Flexible Motor Compatibility: Supports both synchronous and asynchronous motors
Industrial Durability: Designed for harsh environments with wide temperature tolerance
Technical FAQs
1. What motor capacity does this drive support?
Up to 22 kW (normal duty) and 18.5 kW (heavy duty).
2. What is the input voltage range?
380–480 V AC, three-phase supply.
3. What is the rated output current?
Approximately 46.3 A under normal duty conditions.
4. What communication protocols are supported?
Ethernet, Modbus TCP, Modbus RTU, and RS-485.
5. Does it include safety features?
Yes, Safe Torque Off (STO) with SIL3 certification.
6. What is the maximum output frequency?
Up to 500 Hz standard, extendable depending on configuration.
7. Can it control different motor types?
Yes, both synchronous and asynchronous motors are supported.
8. What is the cooling method?
Forced convection cooling ensures stable operation.
9. Does it include an EMC filter?
Yes, integrated EMC filters compliant with IEC standards.
10. What industries commonly use this model?
Water treatment, HVAC, oil & gas, mining, and manufacturing sectors.
