Schneider ATV630D45N4 Altivar Process ATV630 Series 45kW Intelligent Variable Frequency Drive for Industrial Process and Energy‑Efficient Motor Control
Schneider ATV630D45N4 Altivar Process ATV630 Series 45kW Intelligent Variable Frequency Drive for Industrial Process and Energy‑Efficient Motor Control
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV630D45N4 Product Origin:France Product Dimensions:650 × 242 × 318 mm Product Weight:27 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV630D45N4 is a high‑performance variable frequency drive from the Altivar Process ATV630 series, engineered for industrial process, utility, and infrastructure applications. With a rated power of 45kW (60HP), this drive delivers intelligent motor control, advanced diagnostics, and energy efficiency for challenging environments such as water treatment, HVAC, mining, and manufacturing.
As a modern evolution of Schneider’s legacy Altivar platforms, the ATV630D45N4 combines proven drive performance with built‑in Ethernet connectivity, energy monitoring, and safety features—making it ideal for Industry 4.0 automation and energy‑aware control systems.
Technical Specifications
Parameter
Specification
Model
ATV630D45N4
Product Type
Variable Frequency Drive (VFD)
Series
Altivar Process ATV630
Rated Power
45 kW (Normal Duty) / ~37 kW (Heavy Duty)
Input Voltage
380–480 V AC (3‑phase)
Rated Output Current
Approx. 100 A (ND)
Output Frequency
0.1 – 500 Hz (up to ~599 Hz configurable)
Control Method
Vector Control, V/F, Process Control
Communication
Ethernet, Modbus TCP, Modbus RTU, RS‑485
Safety
Safe Torque Off (STO), SIL3
EMC Filter
Integrated (IEC class C2/C3)
Protection Rating
IP21 (UL Type 1)
Cooling Method
Forced convection
Operating Temperature
-15°C to +60°C
Dimensions (H × W × D)
~650 × 242 × 318 mm
Weight
Approx. 27 kg
Mounting Type
Wall / Panel Mount
Technical data compiled from industrial product information (mroelectric.com, plc‑direct.com)
Recommended Related Models
ATV630D22N4 – 22 kW version for medium process loads
ATV630D18N4 – 18.5 kW drive for lower‑power systems
ATV610U45N4 – Cost‑optimized process drive alternative
ATV930D45N4 – High‑end process drive with deeper analytics
ATV320D45N4C – Machine automation drive for OEM systems
Popular Schneider Electric Models
Altivar 630 Series Process Drives
Altivar 610 Series Drives
Altivar 320 Machine Drives
Modicon M580 PLC
EcoStruxure™ Automation Suite
Applications
The ATV630D45N4 is designed for robust industrial motor control and process optimization:
Wastewater and water treatment plants
HVAC systems (large fans, chillers, pumps)
Oil & gas processing and utility systems
Mining and material handling
Food & beverage process lines
Industrial pumping and fluid transfer systems
Advantages
Energy‑Aware Operation: Built‑in energy monitoring and “Stop & Go” functions help reduce energy usage and operating cost.
Smart Connectivity: Native Ethernet and Modbus TCP/R support seamless integration with modern SCADA, DCS, and IoT platforms.
Advanced Process Intelligence: Embedded diagnostics, trend logging, and predictive maintenance features increase uptime and reduce unplanned downtime.
High Safety Standard: SIL3‑rated Safe Torque Off (STO) provides enhanced safety compliance.
Flexible Motor Compatibility: Supports both synchronous and asynchronous motors with multiple control profiles.
Industrial Durability: Designed for harsh environments with wide temperature tolerance and robust cooling.
Technical FAQs
1. What motor power can this drive handle?
It supports up to 45 kW (60 HP) in normal duty and ~37 kW in heavy duty.
2. What is the input voltage requirement?
380–480 V AC, 3‑phase supply.
3. What communications protocols are supported?
Ethernet, Modbus TCP, Modbus RTU, and RS‑485 are supported.
4. Does it include safety features?
Yes, it has Safe Torque Off (STO) with SIL3 certification.
5. What is the maximum output frequency?
Standard up to 500 Hz, configurable up to ~599 Hz.
6. Can it work with different motor types?
Yes, both asynchronous and synchronous motors are supported.
7. Is an EMC filter included?
Yes, integrated EMC filters compliant with IEC standards are included.
8. Is it suitable for continuous operation?
Yes, it is designed for continuous industrial duty.
9. What industries commonly use this model?
Water/wastewater, HVAC, oil & gas, mining, food & beverage, and general manufacturing.
10. How does it compare to ATV61/ATV610 product lines?
ATV630 offers smarter connectivity, advanced diagnostics, and energy analytics, making it a future‑ready process drive.
