Schneider ATV630U22N4 Altivar Process ATV630 Series 22 kW (30 HP) Intelligent Variable Frequency Drive for Industrial Process and Energy‑Efficient Motor Control
Schneider ATV630U22N4 Altivar Process ATV630 Series 22 kW (30 HP) Intelligent Variable Frequency Drive for Industrial Process and Energy‑Efficient Motor Control
0.0
Points
Brand:Schneider PLC Item No.:Schneider ATV630U22N4 Product Origin:France Product Dimensions:500 × 211 × 232 mm Product Weight:15 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATV630U22N4 is a high‑performance variable frequency drive from the Altivar Process ATV630 family, engineered for demanding industrial process applications such as pumps, fans, compressors, and fluid handling systems. With a rated power of 22 kW (30 HP) it delivers advanced motor control, energy‑saving performance, and seamless connectivity for modern automation systems.
As a next‑generation drive, the ATV630U22N4 combines intelligent diagnostics, embedded safety features, and Ethernet‑ready communication, making it ideal for Industry 4.0‑capable plants, SCADA/DCS integration, and energy‑aware facilities. Its compact and robust design supports continuous industrial use while simplifying installation and commissioning. (digikey.com)
Technical Specifications
Parameter
Specification
Model
ATV630U22N4
Product Type
Variable Frequency Drive (VFD)
Series
Altivar Process ATV630
Rated Power
22 kW (Normal Duty) / ~18.5 kW (Heavy Duty)
Input Voltage
380 – 480 V AC, 3‑phase
Rated Output Current
Approx. 45 A (normal duty)
Output Frequency
0.1 – 500 Hz
Control Methods
V/F control, Vector Control, Process Control
Communication
Ethernet, Modbus TCP, Modbus RTU/Serial
Safety
Safe Torque Off (STO), SIL 3
EMC Filter
Integrated — IEC/EN 61800‑3 compliant
Protection Rating
IP21 / UL Type 1
Cooling Method
Forced convection
Operating Temperature
-15 °C to +60 °C
Dimensions (H × W × D)
Approx. 500 × 211 × 232 mm
Weight
Approx. 13‑15 kg
Mounting Type
Wall / Panel mount
Technical data compiled from manufacturer and authorized distributor specifications (digikey.com)
Recommended Related Models
ATV630U15N4 – 15 kW version for lighter process loads
ATV630U30N4 – 30 kW mid‑range drive for greater capacity
ATV630D22N4 – Alternative process drive with diagnostic enhancements
ATV610U22N4 – Legacy‑series cost‑efficient process drive
ATV320U22N4C – Machine automation drive for OEM control
Popular Schneider Electric Models
Altivar 630 Series Process Drives
Altivar 320 Machine Drives
Altivar 610 Series Drives
Modicon M580 PLC
TeSys Motor Control & Protection Systems
Applications
The ATV630U22N4 is ideal for a wide range of industrial automation and process control scenarios:
Water and wastewater treatment pump stations
HVAC fan and chiller motor control
Oil & gas process and utility systems
Mining and material handling applications
Food & beverage processing lines
Industrial pumping and fluid transfer systems
Advantages
Energy‑Efficient Performance: Tailored control profiles reduce energy consumption and improve motor life.
Smart Connectivity: Native Ethernet and Modbus support enable seamless SCADA and PLC integration.
Enhanced Safety: Safe Torque Off (STO) with SIL3 certification improves operator and machine protection.
Advanced Diagnostics: Built‑in monitoring and fault analysis support predictive maintenance.
Flexible Motor Control: Supports both synchronous and asynchronous motors with multiple control modes.
Industrial‑Ready Design: Forced convection cooling and IP21/UL Type 1 rugged construction support long duty cycles and harsh environments.
Technical FAQs
1. What motor capacity can the ATV630U22N4 handle?
Up to 22 kW (30 HP) in normal duty and ~18.5 kW in heavy‑duty mode.
2. What is the input voltage range?
380 – 480 V AC, three‑phase.
3. What communication options are available?
Ethernet, Modbus TCP, and Modbus RTU (serial).
4. Does it include safety features?
Yes — Safe Torque Off (STO) with SIL3 certification.
5. What is the maximum output frequency?
Up to 500 Hz.
6. Is an EMC filter integrated?
Yes, compliant with IEC/EN 61800‑3 standards.
7. What control methods are supported?
V/F control, vector control, and process‑optimized control profiles.
8. Is this drive suitable for continuous industrial use?
Yes — designed for 24/7 operation in industrial environments.
9. Can it work with different motor types?
Yes — compatible with both asynchronous and synchronous motors.
10. What mounting method is recommended?
Wall or panel mounting with forced convection cooling.
