The Schneider Electric ATV71HU75N4 is a 75 kW high-performance compact variable frequency drive engineered for medium-to-heavy industrial applications. Designed for high-demand machinery such as pumps, fans, conveyors, and compressors, this drive provides precise motor control, energy optimization, and operational reliability. The ATV71HU75N4 combines compact design with advanced features to reduce energy costs, enhance motor performance, and support scalable automation solutions in modern industrial environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Input Voltage | 380 – 480 V AC, 3-phase |
| Output Voltage | 0 – 480 V AC |
| Rated Current | 125 A |
| Motor Power | 75 kW (100 hp) |
| Switching Frequency | 2 – 16 kHz |
| Control Modes | V/F, Sensorless Vector, Closed-loop Vector |
| Communication Protocols | Modbus RTU, CANopen, Ethernet/IP |
| Protection Class | IP20 standard, IP54 optional |
| Ambient Operating Temperature | -10°C to 50°C |
| Dimensions (H × W × D) | 700 × 260 × 320 mm |
| Weight | 68 kg |
