Brand:Emerson Module Item No.:KL4503X1-BA1 Product Origin:USA Product Dimensions:50.8 × 97 × 125 mm Product Weight:0.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson KL4503X1-BA1 Bottom Pendant Extender provides a practical solution to extend the reach of DeltaV™ bottom pendants. Its compact, durable design allows improved operator access and ergonomics while maintaining system reliability. Suitable for new installations or retrofits, it enhances safety and operational efficiency in industrial environments.
Technical Specifications
Parameter
Specification
Model
KL4503X1-BA1
Product Type
Bottom Pendant Extender
Dimensions
50.8 × 97 × 135 mm
Weight
0.11 kg
Compatible Series
Emerson DeltaV™ Bottom Pendants
Suggested Alternatives
Model
Product Name
Emerson KL4503X1-BB1
Bottom Pendant Extender
Emerson KL4502X1-MA1
Terminal Blocks
Emerson KL4501X1-BB1
Address Plug
Emerson KL4503X1-BA2
Extended Bottom Pendant
Frequently Selected Together
Model
Product Name
Emerson KJ4001X1-CB1
Output Module with Terminal Blocks
Emerson KL4501X1-BB1
Address Plug
Emerson KJ3243X1-BB2
DP Interface Card
Emerson KL4502X1-MA1
Terminal Blocks
Application Scenarios
• Extends the connection of bottom pendant devices in Emerson DeltaV™ control systems.
• Provides additional reach for operator interfaces in control panels or machinery.
• Commonly used in chemical, oil & gas, and power generation industries.
• Ideal for retrofits or installation where standard pendant reach is insufficient.
• Ensures safe and ergonomic positioning of operator interfaces.
Key Advantages
• Compact and lightweight design allows easy installation and minimal space usage.
• Enhances operator access and ergonomics for control panels.
• Rugged construction suitable for industrial environments.
• Simplifies wiring and connection of pendant devices.
• Compatible with Emerson DeltaV™ bottom pendants for seamless integration.
• Improves safety and operational efficiency in critical processes.
Technical FAQs
1. What is the primary function of this extender?
It extends the reach of Emerson DeltaV bottom pendant devices for improved accessibility.
2. Is it compatible with all DeltaV bottom pendants?
It is designed for DeltaV™ bottom pendant devices.
3. Can it be used in industrial environments?
Yes, it is built to withstand vibration, temperature variations, and general industrial conditions.
4. How is it installed?
It attaches directly to the bottom pendant and provides additional length to reach operator position.
5. What industries typically use this extender?
Chemical, oil & gas, power generation, and other industrial automation sectors.
6. Does it affect signal or control performance?
No, it only extends physical reach; signal integrity is maintained.
7. What is the module’s dimensions and weight?
50.8 × 97 × 125 mm; 0.11 kg.
8. Can it be used for retrofits?
Yes, it is ideal for upgrading existing bottom pendants with limited reach.
9. Is maintenance required?
No, it is maintenance-free under normal operating conditions.
10. Does it improve operator ergonomics?
Yes, it provides better reach and positioning for safer and easier operation.
