The Schneider BMEXBP1002 is a heavy‑duty 10‑slot backplane rack designed for Modicon X80 automation systems. As a dual Ethernet and X‑bus carrier with redundant power supply support, this rack provides the backbone for complex PLC architectures where reliability and scalability matter most. Its robust metal design and industry‑proven platform ensure secure module retention and consistent communication performance. Whether deployed in manufacturing automation, process control, or distributed control environments, the BMEXBP1002 delivers flexible configuration and high uptime for mission‑critical applications.

Technical Specifications

Feature	Specification
Brand	Schneider Electric
Model	BMEXBP1002
Product Type	Modicon X80 Backplane Rack
Slot Count	10 total (8 dual Ethernet/X‑bus, 2 X‑bus only)
Power Supply Support	Dual (Redundant) power supply configuration
Compatible Modules	BMXCPS4002, BMX Processors, BME Processors, I/O and Comm modules
Current Draw	162 mA @ 24 V DC; 76 mA @ 3.3 V DC
Power Consumption	Approx. 3.9 W @ 24 V DC; 0.251 W @ 3.3 V DC
MTBF	~1,770,000 hours
Protection Rating	IP20
Operating Temperature	0–60 °C (32–140 °F)
Mounting	Panel or chassis mount (4 screws)
Dimensions	Approx. 105 × 376 × 19 mm
Weight	~1.37 kg

Recommended Related Models

Schneider BMEXBP0602 – 6‑slot redundant Ethernet/X‑bus backplane for compact systems
Schneider BMEXBP0800 – 8‑slot Ethernet & X‑bus rack for smaller automation cabinets
Schneider BMEXBP0400 – 4‑slot modular backplane rack for basic control systems

Popular Schneider Models

Schneider Modicon M580 – High‑performance automation controller
Schneider BMEH586040 – Redundant processor for high‑availability systems
Schneider BMENOC0301 – Ethernet communication module for distributed automation

Applications

Central backplane in medium to large PLC automation systems
Distributed control systems with mixed I/O and communication modules
High‑reliability manufacturing and process plants
Networked PLC systems requiring redundant power support
Flexible control closet configurations for industrial control panels

Advantages

High Slot Density: 10 slots accommodate a mix of processors, I/O, and communication modules for flexible system architectures.
Redundant Power Support: Dual power paths help maintain uptime in critical applications.
Dual Ethernet/X‑bus Capability: Supports mixed communication and X‑bus module deployment across the same rack.
Proven Industrial Reliability: High MTBF and robust construction deliver long‑term performance.
Industry Standard Footprint: Compatible with a wide range of Modicon X80 modules, reducing inventory and training costs.

Technical FAQs

What does the BMEXBP1002 rack do in a control system?
It provides mechanical and electrical support for multiple Modicon X80 modules, including processors, I/O, and communication cards.
How many slots are available on this backplane?
There are 10 total slots, with 8 hybrid Ethernet/X‑bus and 2 dedicated X‑bus slots.
Can this backplane support redundant power supplies?
Yes — its design accommodates dual power configurations to enhance reliability.
Which module families are compatible?
It works with BMXCPS4002 power supplies, BMX processors, BME processors, and other X80 I/O and comm modules.
Is the rack suitable for harsh industrial environments?
The standard model is rated IP20 and suitable for indoor industrial control panels.
What is the typical operating temperature range?
It operates reliably between 0 °C to 60 °C.
How much power does the backplane consume?
Around 3.9 W at 24 V DC and 0.251 W at 3.3 V DC.
Can modules be hot‑swapped in this rack?
Module insertion/removal practices depend on the PLC system design and power state but the rack supports flexible configurations.
What’s the reliability metric for this product?
It has a mean time between failures (MTBF) of approximately 1,770,000 hours.
What mounting options does the backplane support?
It can be mounted on a panel or chassis using 4 screws.
