The Schneider BMXFCW303 is an advanced communication module for Modicon X80 PLC and I/O systems, providing reliable and high-speed fieldbus connectivity. Engineered for demanding industrial environments, it ensures seamless integration between controllers and distributed I/O modules. With robust diagnostics and industrial-grade protection, the BMXFCW303 guarantees secure, continuous communication, making it ideal for automated production lines, process control, and machine monitoring systems.
Technical Specifications
| Feature | Specification |
|---|---|
| Brand | Schneider Electric |
| Model | BMXFCW303 |
| Module Type | Communication Module (Modicon X80) |
| Communication Protocol | Fieldbus compatible (e.g., Profibus DP, CANopen) |
| Data Rate | Up to 12 Mbps |
| Connector Type | Standard X80 backplane and field connectors |
| Status Indicators | RUN, ERR, LINK LEDs |
| Operating Temperature | 0 °C to +60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Shock Resistance | 30 gn |
| Vibration Resistance | 3 gn |
| Protection Rating | IP20 |
| Power Consumption | ~5 W |
| Dimensions (L × W × H, mm) | 120 × 90 × 70 mm |
| Weight | ~250 g |
Recommended Related Modules
- Schneider BMEXBP1002 – 10-slot backplane rack for X80 modules
- Schneider BMXDDO3202K – 32-channel discrete output module
- Schneider BMXDDI3202K – 32-channel discrete input module
