The Schneider Electric TM2AMM3HT is a high-performance analog output expansion module designed for Modicon M238 PLC systems. It provides 3 high-speed single-ended analog output channels, supporting both voltage and current outputs for precise process control.
This module is ideal for applications requiring fast, reliable, and accurate signal output, such as actuator control, valve positioning, and industrial automation systems. Its compact design ensures seamless integration into TM2 modular PLC systems while maintaining high operational reliability.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Analog Output Expansion Module |
| Series | Modicon TM2 (for M238 PLC) |
| Output Channels | 3 |
| Output Type | Single-ended |
| Output Range (Voltage) | 0–10 V / ±10 V |
| Output Range (Current) | 0–20 mA / 4–20 mA |
| Resolution | 12-bit |
| Update Time | Approx. 5 ms per channel |
| Output Impedance | ≤ 1 Ω (voltage) / ≥ 500 Ω (current) |
| Power Supply | Via PLC backplane ribbon cable |
| Mounting | DIN rail |
| Dimensions (H × W × D) | Approx. 90 × 50 × 70 mm |
| Weight | Approx. 0.18 kg |
| Operating Temperature | 0°C to 55°C |
Dimensions and weight are based on standard TM2 module specifications.
