The Schneider Electric TM2DDO32UK is a high‑channel‑count digital output expansion module designed for Modicon M238 PLC systems. It provides 32 independent transistor outputs capable of driving external loads such as relays, indicators, solenoids, and small actuators. Combining high density with compact design and reliable performance, this module is ideal for industrial automation, machine control, and process applications where multiple output channels are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital Output Module |
| Series | Modicon TM2 (for M238 PLC) |
| Output Channels | 32 |
| Output Type | Transistor (PNP/NPN compatible) |
| Nominal Load Voltage | 24 V DC |
| Maximum Load Current | 0.5 A per channel |
| Load Type | Resistive or inductive loads |
| Output Isolation | Optically isolated |
| Response Time | Approx. 1 ms |
| Power Supply | Powered via PLC backplane |
| Mounting | DIN rail |
| Dimensions (H × W × D) | Approx. 90 × 100 × 70 mm |
| Weight | Approx. 0.32 kg |
| Operating Temperature | 0°C to 55°C |
