The Schneider Electric TM3DQ8R is an 8‑channel digital relay output module designed for Modicon TM3 PLC systems. Providing reliable switching of external loads through electromechanical relay outputs, this module is well suited for industrial control, machine automation, and process systems where isolation and versatile load support are required.
With a compact footprint and robust design, TM3DQ8R delivers dependable control for discrete outputs such as indicator lights, solenoids, contactors, and other electromechanical devices.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Digital Output Module |
| Series | Modicon TM3 (for TM3 PLC) |
| Output Channels | 8 |
| Output Type | Relays (Form A / SPST) |
| Nominal Load Voltage | Up to 250 V AC / 30 V DC |
| Maximum Load Current | 2 A per channel |
| Load Compatibility | Resistive / Inductive |
| Output Isolation | Relay isolation |
| Response Time | Approx. 10 ms |
| Power Supply | Powered via PLC backplane |
| Mounting | DIN rail |
| Dimensions (H × W × D) | Approx. 90 × 50 × 70 mm |
| Weight | Approx. 0.20 kg |
| Operating Temperature | 0 °C to 55 °C |
