Schneider Electric TM3XREC1 Recorder Expansion Module for Modicon TM3 PLC Systems

Applications

The TM3XREC1 is suitable for:

• Process value logging, trends, and historical analysis
• Quality control and process traceability
• Event and alarm recording
• Batch monitoring in manufacturing
• Environmental and HVAC data capture

Advantages

• Time‑Based Data Logging: Record process values and events over time
• Flexible Configuration: Channels and intervals set via PLC logic
• Seamless Integration: Designed to work with Modicon TM3 PLC systems
• Space‑Efficient Design: Compact DIN rail module
• Supports Mixed Signals: Analog, digital, and event data capture

Technical FAQs

1. What is the primary function of this module?
   It provides recorder expansion for logging and archiving process data.
2. How many channels can it record from?
   Up to 8 configurable channels.
3. What types of signals can be recorded?
   Analog values, digital states, and system events.
4. Does it require additional power supply?
   No — it is powered via the PLC backplane connection.
5. What are the physical dimensions?
   Approximately 90 × 50 × 70 mm (H × W × D).
6. What is the weight of the module?
   Approximately 0.20 kg.
7. Is it compatible with TM3 PLC systems?
   Yes — specifically designed for Modicon TM3 PLCs.
8. Can the recording interval be configured?
   Yes, it can be configured via the PLC program.
9. Can it record alarms and events?
   Yes — supports digital event recording.
10. What environments is it suitable for?
    Industrial automation, process monitoring, and quality control systems.
