The Schneider TSX3705001 is a rugged, high‑performance Programmable Logic Controller (PLC) Module designed for industrial automation applications where reliability, scalability, and real‑time control are essential. Engineered as part of the durable Modicon TSX Micro series, this CPU module integrates logic processing with built‑in inputs and outputs to simplify system design and accelerate deployment. Its robust hardware platform and proven field record make it a trusted choice for manufacturers, integrators, and automation professionals seeking smooth operation under demanding conditions.

Technical Specifications

Specification	Detail
Model	TSX3705001
Module Type	PLC CPU Module with Built‑in Digital I/O
Input Power	100–240 V AC
Digital Inputs	16 discrete
Outputs	12 relay outputs (0.5 A each)
Expansion Capability	2 modular slots
Memory	~11 Kwords RAM, ~12 Kwords Flash
Communication Protocols	Uni‑Telway, Modbus RTU
Operating Temperature	0 °C to 80 °C
Humidity Range	10 %–95 % non‑condensing
Dimensions (Approx.)	170 × 151 × 152 mm
Weight (Approx.)	1.4 kg

Recommended Related Models

Model	Why It’s Recommended
Schneider TSX3710101 PLC CPU	Extended performance and communication options for larger I/O systems
Schneider TSXASZ401 Output Module	Compatible expansion module to increase discrete outputs
Schneider TSXDMI401 Input Module	Additional inputs for expanded control needs
Schneider TSXPCX3030 Communication Module	Adds networking flexibility for remote systems

Popular Schneider Models

Model	Key Strength
Schneider Modicon M221	Compact controller with intuitive programming
Schneider Modicon M241	Mid‑range PLC with Ethernet and advanced functions
Schneider Modicon M580	High‑performance ePAC for enterprise automation
Schneider Modicon Quantum	Modular PLC family for large, complex systems

Applications

The TSX3705001 excels across a wide range of automation environments:

Machine control and sequencing in discrete manufacturing
Material handling and conveyor systems
Packaging line logic and safety interlocks
HVAC system automation and facility control
Retrofit projects replacing aging PLC platforms

Advantages

Integrated I/O Reduces Complexity: Built‑in digital inputs and outputs simplify panel design and reduce additional module costs.
Expandable Architecture: Two expansion slots allow easy scaling of I/O or communications as project demands evolve.
Robust Industrial Durability: Designed to withstand wide temperature and humidity ranges typical in factory environments.
Trusted Long‑Term Performance: Part of the well‑established Modicon TSX family with decades of field reliability.
Flexible Communications: Supports industry‑standard protocols for seamless integration with supervisory systems and remote devices.

Technical FAQs

What class of device is the TSX3705001?
It’s a modular PLC CPU with built‑in digital I/O for compact automation systems.
How many I/O points are built into the unit?
The module includes 16 digital inputs and 12 relay outputs.
Can I expand the I/O beyond what’s built in?
Yes — two expansion slots support additional I/O or communication modules.
What communication standards are supported?
Uni‑Telway and Modbus RTU are available for serial integration.
What power supply range does it accept?
The CPU operates on 100–240 V AC, accommodating a broad industrial power range.
What are its physical dimensions?
Roughly 170 × 151 × 152 mm, suitable for standard control cabinets.
Is this controller suitable for harsh industrial conditions?
Yes — it’s specified to operate across extended temperature and humidity ranges.
Does it retain program memory on power loss?
Yes — flash storage ensures program retention during power interruptions.
Where is this controller best applied?
Ideal for machine control, packaging automation, process sequencing, and retrofits.
Can this PLC interface with higher‑level systems?
Yes — supported protocols allow integration with SCADA, HMIs, and other automation networks.
