ABB 5SHX1060H0003 Power Supply Module

Introduction

The ABB 5SHX1060H0003 is a powerful and reliable Power Supply Module designed for industrial automation systems. This module provides stable and efficient DC power to ABB control units, sensors, actuators, and other essential components in automated systems. Engineered to meet the demanding needs of high-performance industrial environments, the 5SHX1060H0003 ensures continuous operation with minimal downtime and maximum system efficiency.

With its high power output, advanced protection features, and compact design, this power supply module is ideal for powering various industrial control systems and automation equipment. It ensures the integrity of complex systems by delivering a consistent power source, essential for maintaining automation reliability in manufacturing, energy, process control, and other mission-critical applications.

Technical Specifications

Specification	Details
Model	5SHX1060H0003
Module Type	Power Supply Module
Input Voltage	100-240 V AC, 50/60 Hz
Output Voltage	24 V DC
Output Current	60 A
Rated Power	1440 W
Efficiency	>90%
Protection	Short-circuit, Over-voltage, Overload Protection
Dimensions (W x H x D)	125 × 160 × 210 mm
Weight	3.0 kg
Operating Temperature	0°C to +60°C
Storage Temperature	-20°C to +85°C
Certifications	CE, UL, RoHS

Recommended Related Models

Model	Module Type	Key Feature
ABB 5SHX1065H0003	Power Supply Module	Higher output current for demanding applications
ABB 5SDF0460F0001	Power Supply Module	Compact design with robust power conversion capabilities
ABB 5SGX0850F0001	Power Supply Module	Increased power output with enhanced efficiency

Popular ABB Models

Model	Module Type	Key Feature
ABB 5SGX0845F0001	Power Supply Module	Efficient power supply for industrial applications
ABB 5SHY3545L0010	Power Supply Module	Reliable and compact solution for industrial automation
ABB 5SHY3545L0014	Power Supply Module	High power capacity for large-scale automation systems

Applications

Industrial Automation: The 5SHX1060H0003 is ideal for powering control systems and automation equipment in manufacturing, production lines, and robotics.
Energy & Utilities: It ensures stable and efficient power distribution in energy plants, substations, and water treatment facilities, supporting critical infrastructure.
Process Control Systems: Perfect for chemical plants, food processing, and oil & gas operations where continuous power supply is crucial for system stability and safety.
Building Automation: Used to supply power to HVAC, lighting systems, and smart building control systems, ensuring optimal performance and energy efficiency.

Advantages

High Power Output: With 60 A output current and 1440 W rated power, the 5SHX1060H0003 can meet the needs of large-scale automation systems and high-demand applications.
Compact and Durable Design: Despite its high power output, the module is designed to fit within a 125 × 160 × 210 mm form factor and weighs 3.0 kg, making it easy to integrate into space-limited environments.
Advanced Protection Features: Equipped with short-circuit, over-voltage, and overload protection, the 5SHX1060H0003 ensures safe operation and long-term reliability.
High Efficiency: The module boasts an efficiency of >90%, helping reduce energy consumption and operational costs, while maximizing system performance.
Wide Temperature Range: The module operates within a temperature range of 0°C to +60°C, making it suitable for diverse industrial environments, from cold storage facilities to high-temperature factory floors.

Technical FAQs

What is the input voltage for the ABB 5SHX1060H0003?
The module supports 100-240 V AC input voltage, which makes it compatible with global power standards.
What is the output voltage and current of the module?
The module provides a stable 24 V DC output with 60 A of current, ideal for powering a range of industrial control systems.
What is the rated power of the 5SHX1060H0003?
This power supply module provides 1440 W of power, ensuring that even high-power industrial systems can operate without interruption.
What protection features are included in this module?
The 5SHX1060H0003 includes short-circuit, over-voltage, and overload protection, ensuring safe and reliable operation under varying electrical conditions.
What is the efficiency of the 5SHX1060H0003?
The module has an efficiency rating of >90%, making it highly energy-efficient and reducing operational costs.
What are the physical dimensions and weight of this module?
It measures 125 × 160 × 210 mm and weighs 3.0 kg, making it compact for integration in tight spaces.
What is the operating temperature range for the module?
The 5SHX1060H0003 operates in a temperature range of 0°C to +60°C, ensuring reliable performance in various industrial conditions.
Is the 5SHX1060H0003 certified for use in international markets?
Yes, it is certified with CE, UL, and RoHS, meeting international safety, quality, and environmental standards.
Can this module be used in high-demand industrial applications?
Yes, it is designed to deliver 1440 W of power, making it suitable for high-demand environments like automated manufacturing and process control systems.
What industries benefit from the ABB 5SHX1060H0003?
This module is ideal for industrial automation, energy, process control, and building automation, ensuring consistent and reliable power for critical operations.
