The Schneider VW3A1113 is a compact plain text display terminal designed for Altivar variable speed drives, providing essential monitoring, configuration, and diagnostics in industrial automation systems. With a 128 × 64 pixel backlit LCD screen, it delivers clear real-time information for operators while maintaining a simple and efficient interface. Compatible with Altivar Easy 610 and ATV340 series, it is widely used for machine control, HVAC systems, and general industrial drive applications where reliable local access is required.

Technical Specifications

Specification	Detail
Model	VW3A1113
Module Type	Plain Text Display Terminal
Product Range	Altivar
Compatible Series	Easy Altivar 610, Altivar Machine ATV340
Display Type	Backlit LCD screen
Resolution	128 × 64 pixels
Display Format	2 lines of text
Function	Monitoring, configuration, parameter transfer
User Language Support	Multi-language (varies by firmware)
Real-Time Clock	Not included
Communication Interface	RJ45 connection to drive
Mounting Type	Panel / enclosure door (with accessory kit)
Protection Rating	IP21
Dimensions (L×W×H)	124×92×92 mm
Weight	0.09 kg
Operating Temperature	−15 °C to 50 °C
Storage Temperature	−20 °C to 70 °C
Installation	Front-mounted or remote via accessories
Lifecycle Status	Active / widely used accessory

Recommended Related Models

Model	Why It’s Recommended
VW3A1111	Graphic display terminal (higher function HMI)
VW3A1006	Basic remote terminal (IP54 protection)
VW3A1007	IP65 keypad terminal for harsh environments
VW3A1105	RJ45 adapter for communication extension

Popular Schneider Altivar Series

Series	Key Strength
Altivar 12	Compact drive for simple machines
Altivar 32	General-purpose industrial drive
Altivar 340	Machine automation with advanced control
Altivar 610	Easy process and HVAC control

Applications

Local monitoring and configuration of variable speed drives
Industrial control panels and machine interfaces
HVAC, pumps, and conveyor systems
Retrofit and maintenance of Altivar installations
Parameter adjustment and diagnostics in field operations

Advantages

Compact HMI Design: Simple and efficient operator interface for daily use
Clear LCD Display: 128×64 resolution ensures readable process information
Easy Integration: Direct compatibility with Altivar drive systems
Industrial Reliability: Designed for stable operation in control cabinets
Cost-Effective Solution: Ideal balance between functionality and simplicity

Technical FAQs

What is the VW3A1113 used for?
It is a plain text display terminal for Altivar drives used for monitoring and configuration.
What display does it use?
A 128×64 pixel backlit LCD screen.
Which drives is it compatible with?
Altivar Easy 610 and ATV340 series.
Does it support graphical display?
No, it is a plain text (non-graphic) terminal.
What is the protection rating?
IP21.
What are its dimensions?
124×92×92 mm.
What is the weight?
Approximately 0.09 kg.
Can it be panel mounted?
Yes, with appropriate installation accessories.
Does it include a real-time clock?
No, it does not include RTC functionality.
What is its main advantage?
Simple, reliable local control and diagnostics for Altivar drives.
