The Schneider VW3A3501 is a high-performance Controller Inside programmable card designed for Altivar 61 and Altivar 71 variable speed drives, enabling embedded control logic directly inside the drive. Instead of relying on an external PLC, this module allows users to implement advanced automation, sequencing, and process control functions within the drive itself, significantly simplifying system architecture and improving response speed.
This solution is widely used in complex machine systems, process automation, and OEM equipment where integrated control and reduced cabinet complexity are required.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | VW3A3501 |
| Module Type | Controller Inside Programmable Card |
| Compatible Drives | Altivar 61 / 61Q / Altivar 71 / 71Q / Lift |
| Function | Embedded PLC / drive-integrated control logic |
| Programming Environment | CoDeSys-based control (IEC 61131-3 compatible) |
| Processor Speed | 40 MHz |
| I/O Capability | Multiple digital + analog inputs/outputs via drive system |
| Communication | Fieldbus via drive network options (Profibus, CANopen, etc.) |
| Connector Type | 9-way male SUB-D interface |
| Power Supply | 24 V DC (via drive backplane) |
| Memory | Program + application memory embedded |
| Control Function | Logic sequencing, PID, interlocking, automation routines |
| Installation | Internal plug-in option card |
| Dimensions (L×W×H) | 160×90×40 mm |
| Weight | 0.32 kg |
| Operating Temperature | 0 °C to 50 °C |
| Storage Temperature | −25 °C to 70 °C |
| Protection Rating | Installed inside drive enclosure |
