The Schneider Electric XBT0T2210 (Magelis XBT OT series) is a compact industrial HMI touchscreen operator panel designed for real-time machine visualization, control, and diagnostics in automation systems. It provides a reliable human–machine interface between operators and PLC-controlled equipment, making it widely used in manufacturing, process control, and OEM machine integration environments.

Built with Schneider’s industrial-grade design philosophy, this model emphasizes stability, intuitive operation, and long service life, even in demanding factory conditions.

Technical Specifications

Parameter	Details
Model	XBT0T2210
Series	Magelis XBT OT
Display Size	5.7-inch STN LCD
Resolution	320 × 240 pixels (QVGA)
Touch Type	Analog resistive touchscreen
Communication Ports	RS-232 / RS-485
Power Supply	24V DC
Front Protection	IP65 (dust & water resistant front panel)
Operating System	Schneider Vijeo Designer compatible

Mechanical Dimensions (mm)

Length × Width × Height: 212 mm × 156 mm × 60 mm

Weight

Weight: approx. 2.4 kg

Recommended Related Models

Schneider XBTGT2220 (advanced HMI replacement series)
Schneider HMIGTO5310 (modern Magelis GTO touchscreen)
Schneider HMISTO705 (compact EcoStruxure operator panel)
Schneider XBTGC2230T (HMI + PLC integrated unit)

Popular Schneider HMI Models

XBTGT series (mid-range industrial panels)
HMIGTO / HMISTO series (EcoStruxure modern HMI)
XBTGTW / XBTGK advanced panels
Magelis STO & SOT compact interfaces

Applications

Industrial automation control panels
Packaging and labeling machinery
Injection molding systems
Water treatment monitoring systems
HVAC and building automation
Production line visualization terminals

Advantages

Industrial-grade 5.7" intuitive touchscreen interface
Stable communication with multiple PLC systems
Rugged design suitable for harsh environments
IP65-rated front panel protection
Easy integration with Schneider automation ecosystem
Long lifecycle support for industrial maintenance systems
Operator-friendly interface reduces training time
Proven reliability in continuous 24/7 operation

Technical FAQs

1. Is XBT0T2210 still in production?
It is part of an older Magelis series and has been largely replaced by newer Schneider HMI platforms.

2. What software is used for configuration?
It is typically configured using Vijeo Designer software.

3. Can it connect to Siemens PLCs?
Yes, via serial communication protocols such as RS-232/RS-485 with proper configuration.

4. Is the touchscreen resistive or capacitive?
It uses a resistive touchscreen suitable for glove operation.

5. What is the power requirement?
Standard 24V DC industrial power supply.

6. Is it suitable for outdoor use?
Only with proper enclosure; the front is IP65 rated.

7. What industries commonly use it?
Manufacturing, energy systems, water treatment, and OEM machinery.

8. Does it support Ethernet?
This model is primarily serial-based and does not include native Ethernet.

9. What is the typical lifespan?
Industrial usage can exceed 8–10 years depending on environment and maintenance.

10. Can it replace newer Magelis panels directly?
No, newer HMIGTO/HMISTO series require updated configuration and wiring compatibility.
