Emerson KJ3002X1-BF1 Analog Output Module (DeltaV DCS)
Emerson KJ3002X1-BF1 Analog Output Module (DeltaV DCS)
0.0
Points
Brand:Emerson Module Item No.:Emerson KJ3002X1-BF1 Product Origin:USA Product Dimensions:41 × 107 × 105 mm Product Weight:1.13 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson KJ3002X1-BF1 is a high-performance analog output module designed for the DeltaV distributed control system (DCS). It provides accurate and stable signal output to field devices, acting as the critical interface between digital control logic and real-world process actuators.
Engineered for mission-critical industries, this module ensures precise control of valves, positioners, and variable speed drives, making it a core component in automation environments where signal integrity and reliability directly impact production performance.
Technical Specifications (Industrial Analog Output Performance Module)
Parameter
Details
Model
KJ3002X1-BF1
Brand
Emerson
Product Type
Analog Output Module
System Platform
DeltaV DCS
Channels
8 isolated channels
Output Signal
4–20 mA
Resolution
12–16 bit
Accuracy
±0.1% of span
Isolation
Channel-to-channel and system isolation
Field Power
24 V DC
Diagnostics
Loop monitoring / fault detection
Physical Dimensions & Weight
Item
Specification
Dimensions (W × H × D)
41 × 107 × 105 mm
Weight
~1.13 kg
Recommended Related Models (System Expansion Options)
Emerson KJ3002X1-BE1 – Analog output module variant
Emerson KJ3001X1-BB1 – Analog input module
Emerson KJ1501X1-BC1 – System power supply module
Emerson VE4003S6B1 – Terminal block assembly
Emerson DeltaV M-series I/O modules
Popular Emerson Models (Core DeltaV Automation Components)
Emerson DeltaV Controller Modules
Emerson VE4003 Analog I/O Cards
Emerson KJ4001 Power Supply Modules
Emerson DeltaV Operator Workstations
Emerson CHARMs I/O Modules
Applications (Accurate Control Output in Industrial Process Systems)
The KJ3002X1-BF1 is widely used in:
Oil & gas process control systems
Petrochemical and refinery automation
Power plant turbine and boiler control
Chemical production lines
Water treatment dosing and valve control
SCADA and DCS-based industrial automation
It is especially suitable for applications requiring high-precision analog output control with stable long-term performance.
Advantages (High Accuracy, Isolation, and System Reliability)
8-channel isolated analog output architecture
High accuracy (±0.1%) for precise process control
Stable 4–20 mA signal output for industrial standards
Strong electrical isolation improves system safety
Built-in diagnostics for loop integrity monitoring
Seamless integration with DeltaV DCS architecture
Reliable 24/7 operation in harsh industrial environments
Supports critical control loops with minimal signal drift
Technical FAQs
1. What is the KJ3002X1-BF1 used for?
It outputs analog control signals to field devices such as valves and actuators.
2. How many channels does it support?
8 isolated analog output channels.
3. What output signal does it provide?
Standard 4–20 mA industrial analog signal.
4. What is the accuracy?
Approximately ±0.1% of span.
5. What systems is it compatible with?
Emerson DeltaV distributed control systems.
6. What is the weight of the module?
Approximately 1.13 kg.
7. Does it support diagnostics?
Yes, including loop integrity and fault detection.
8. What field power is required?
24 V DC supply.
9. What devices can it control?
Control valves, actuators, and variable speed drives.
10. Why is it important in DCS systems?
Because it converts digital control signals into precise analog outputs for real-world process control.
