Brand:Bently Nevada PLC Item No.:3500/04 Product Origin:USA Product Dimensions:241 x 24.4 x 103.1 mm Product Weight:0.201 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 3500/04 176449-01 + 125680-01 Internal Barriers Module delivers reliable electrical isolation and grounding protection in 3500 Series monitoring racks. It ensures signal integrity, prevents interference, and safeguards sensitive monitoring modules, supporting accurate vibration and proximity measurements in demanding industrial applications.
Technical Specifications
Item
Description
Product Type
Internal Barriers Module
Supported Systems
Bently Nevada 3500 Series Monitoring Racks
Primary Function
Signal isolation, earthing, and channel protection
Signal Channels
Multiple I/O channels with internal separation
Electrical Protection
Minimizes interference and cross-talk for precise measurements
Environmental Resistance
Industrial-grade, vibration and temperature tolerant
Dimensions (H × W × D)
241 × 24.4 × 103.1 mm
Weight
0.201 kg
Deployment
Slot integration for signal protection and earthing
System Integration
Works with other 3500/04 I/O and earthing modules
Maintenance
Visual inspection recommended for secure installation
Recommended Related Models
Model
Module Type
Primary Function
Bently Nevada 3500/04 136719-01
Earthing I/O Module
Rack grounding and signal integrity
Bently Nevada 3500/04 138257-01
Earthing Module Front Panel
Front-panel grounding support
Bently Nevada 3500/04 136719-01+138527-01
Internal Barriers Module
Signal isolation and earthing
Bently Nevada 3500/04-136720
Auxiliary I/O Module
Signal interface extension
Bently Nevada 3500/22
Vibration Monitor Module
Channel monitoring
Bently Nevada 3500/23
Proximitor Module
Shaft displacement measurement
Bently Nevada 3500/42
Transient & Overspeed Module
High-speed signal detection
Bently Nevada 3500/05
Relay Output Module
Alarm and actuation output
Bently Nevada 3500/08
Backup Module
Redundant monitoring support
Bently Nevada 3300 XL Sensor
Vibration Sensor
Rotating machinery monitoring
Popular Related Models
Model
Module Type
Typical Application
Bently Nevada 3500/04 176449-01+125680-01
Internal Barriers Module
Rack signal isolation and grounding
Bently Nevada 3500/04 136719-01+138527-01
Internal Barriers Module
Signal protection and earthing
Bently Nevada 3500/04 136719-01
Earthing I/O Module
Rack grounding and I/O support
Bently Nevada 3500/04 138257-01
Earthing Module Front Panel
Front-panel grounding
Bently Nevada 3500/22
Monitor Module
Vibration channel monitoring
Bently Nevada 3500/23
Proximitor Module
Shaft displacement measurement
Bently Nevada 3500/42
Transient & Overspeed Module
High-speed signal detection
Bently Nevada 3500/75
Remote Display Module
Rack status visualization
Bently Nevada 3500/05
Relay Output Module
Alarm output
Bently Nevada 3300 XL Sensor
Vibration Sensor
Rotating machinery monitoring
Applications
The Bently Nevada 3500/04 176449-01 combined with 125680-01 Internal Barriers Module is engineered to provide robust signal isolation and electrical protection within 3500 Series monitoring racks. It is commonly deployed in industrial machinery monitoring environments, including turbines, compressors, and generators, where precise channel separation and safe signal routing are crucial. This module combination ensures accurate monitoring while protecting sensitive electronics from electrical faults.
Advantages
This module pair enhances system reliability by offering both internal barriers and earthing support. It prevents cross-talk and minimizes interference between channels, maintaining high-fidelity signal transmission. Its compact, rugged design ensures seamless integration into standard 3500 Series racks, providing a durable solution that protects critical monitoring circuits and maintains measurement accuracy in demanding industrial environments.
FAQs
1. What is the function of the 3500/04 176449-01 + 125680-01 module?
It provides internal signal isolation and grounding protection for sensitive monitoring modules within the rack.
2. Is this module compatible with all 3500 Series racks?
Yes, it fits standard 3500 Series monitoring racks requiring internal barriers.
3. Does it reduce electrical interference?
Yes, it isolates channels to prevent cross-talk and ensure clean signal transmission.
4. How many channels can be supported by this module combination?
It supports multiple I/O channels according to the rack’s configuration design.
5. Is user configuration necessary?
No, it operates as a passive internal barrier and earthing module.
6. Can it withstand harsh industrial conditions?
Yes, it is built to handle vibration, temperature changes, and mechanical stress.
7. Does it improve measurement accuracy?
Yes, by maintaining channel isolation, it ensures precise sensor readings.
8. Can it be used alongside other 3500/04 modules?
Yes, it works in conjunction with earthing and I/O modules for full protection.
9. How is it installed in the rack?
It is designed for easy slot integration within the 3500 Series rack system.
10. What maintenance is required?
Visual inspection for secure mounting is recommended; no active maintenance is required.
