Brand:Schneider PLC Item No.:TSXAEY414 Product Origin:France Product Dimensions:55 x 180 x 260 mm Product Weight:0.32 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TSXAEY414 analog input module is engineered for high-precision signal acquisition in Modicon Premium PLC systems. It converts a wide range of analog field signals into accurate digital data, ensuring reliable process monitoring and control in complex industrial environments.
Technical Specifications
Parameter
Details
Product Model
TSXAEY414
Product Type
Analog Input Module
System Compatibility
Modicon Premium Series
Input Channels
4 Analog Inputs
Signal Types
Voltage / Current / RTD / TC
Resolution
16-bit
Mounting Style
Rack / DIN Rail (system-based)
Operating Environment
Industrial
Dimensions
55 × 180 × 260 mm
Weight
0.32 kg
Suggested Companion Units
Model
Product Name
TSXPSY2600
Power Supply Module
TSXDEY16D2
Digital Input Module
TSXDSY16T2
Digital Output Module
TSXETY4103
Ethernet Communication Module
Frequently Selected Alternatives
Model
Product Name
TSXAEY1600
Analog Input Module
TSXAEY1602
Voltage Input Module
TSXAEY801
Current Input Module
TSXAEY414H
High-Precision Analog Input Module
Applications
• Process automation systems
Provides high-precision analog signal acquisition for industrial process control.
• Energy monitoring systems
Enables accurate measurement of voltage, current, and temperature signals in power applications.
• Factory automation lines
Supports real-time analog data collection from sensors in production environments.
• Environmental monitoring systems
Interfaces with temperature, pressure, and flow sensors for continuous monitoring.
• Data acquisition systems
Delivers stable analog input conversion for industrial data logging applications.
Key Advantages
• Multi-signal compatibility
Supports voltage, current, resistance, thermocouples, and RTD inputs in one module.
• High-resolution conversion
Provides 16-bit analog-to-digital conversion for precise signal processing.
• Strong electrical isolation
Ensures safe operation with robust isolation between channels and system ground.
• Industrial-grade reliability
Designed for stable performance in harsh industrial environments.
• Flexible integration
Easily integrates into Modicon Premium PLC architectures.
Technical FAQs
1. How many analog inputs does the TSXAEY414 provide?
It provides 4 configurable analog input channels.
2. What types of signals can it read?
It supports voltage, current, resistance, thermocouples, and RTD sensors.
3. What is the resolution of the module?
It uses 16-bit analog-to-digital conversion for high accuracy.
4. Which PLC system is it designed for?
It is designed for Schneider Modicon Premium automation platforms.
5. Does it support current loop signals?
Yes, it supports standard 4–20 mA and 0–20 mA inputs.
6. Is signal isolation provided?
Yes, it includes galvanic isolation between channels and system bus.
7. What is the typical scan time?
The read cycle time is approximately 550 ms for full processing.
8. Can it be used for temperature measurement?
Yes, it supports thermocouples and RTD temperature sensors.
9. What is the operating temperature range?
It typically operates between 0°C and 60°C in industrial environments.
10. Is it suitable for harsh industrial environments?
Yes, it is designed for reliable operation in demanding conditions.
