Brand:GE Fanuc PLC Item No.:GE IC697VAL132 Product Origin: USA Product Dimensions:266 × 88 × 31 mm Product Weight:1.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC697VAL132 is a high-density analog input module designed for the GE Fanuc Series 90-70 PLC system. It is used to convert industrial analog signals into digital data that can be processed by the PLC CPU.
This module is widely applied in process control, energy systems, and industrial automation environments where accurate signal acquisition from sensors such as pressure, temperature, and flow transmitters is required.
It is not a standalone controller, but an I/O expansion module that significantly enhances the PLC’s analog signal handling capability.
Technical Specifications
Parameter
Details
Manufacturer
GE Fanuc / Emerson
Series
90-70 Series (also used in PACSystems integration)
Model Number
IC697VAL132
Module Type
Analog Input Module
Input Channels
31 single-ended / 16 differential
Signal Type
Current input
Input Range
0–20 mA / 4–20 mA / 5–25 mA
Resolution
12-bit ADC
Isolation
1500V RMS (channel to backplane)
Input Impedance
≥ 10 MΩ
Backplane Power Draw
~2.5 A @ 5 VDC
Function
Analog-to-digital conversion
Compatibility
GE 90-70 PLC system
Diagnostic Features
Built-in test & channel monitoring
Operating Temperature
0°C to 60°C
Physical Dimensions & Weight
Size (L × W × H): 266 × 88 × 31 mm
Weight: 1.36 kg
Recommended Related Models
IC697MDL753 Digital Output Module
IC697MDL940 Relay Output Module
IC697ALG230 Analog Input Module
IC697CPU780 High-Performance CPU
IC697BEM731 Bus Expansion Module
Common GE 90-70 Modules
IC697MDL740 Digital Output Module
IC697MDL753 High-Density Output Module
IC697MEM731 Memory Expansion Module
IC697MSC800 System Interface Module
IC697PWR711 Power Supply Module
Applications
The IC697VAL132 is widely used in industrial environments requiring precise analog signal processing:
Oil & gas pipeline monitoring systems
Power plant process control
Chemical and petrochemical automation
Water treatment and environmental control systems
Manufacturing process measurement and feedback loops
It is especially valuable in systems where high channel density and accurate signal conversion are required.
Advantages
High Channel Density Design
Supports up to 31 single-ended inputs for large-scale monitoring.
High-Precision 12-bit Conversion
Ensures accurate analog-to-digital signal processing.
Strong Electrical Isolation
1500V isolation protects PLC systems from field noise and surges.
Flexible Signal Compatibility
Supports multiple current input ranges (4–20 mA standard industrial loop).
Built-in Diagnostics
Provides self-test and channel monitoring for improved reliability.
Industrial-Grade Reliability
Designed for continuous operation in harsh environments.
Technical FAQs
1. What is the IC697VAL132 used for?
It converts analog current signals from field devices into digital data for PLC processing.
2. Is it a CPU or controller module?
No, it is an analog input I/O module.
3. How many channels does it support?
Up to 31 single-ended or 16 differential channels.
4. What signal types does it accept?
0–20 mA, 4–20 mA, and 5–25 mA current signals.
5. What is its resolution?
12-bit analog-to-digital conversion.
6. Does it provide electrical isolation?
Yes, up to 1500V RMS isolation.
7. What is its weight?
Approximately 1.36 kg.
8. Is it still used today?
Yes, mainly in legacy GE 90-70 industrial systems.
9. What industries use it most?
Process industries like oil, gas, chemical, and power generation.
10. Why is it important in PLC systems?
Because it enables accurate real-time monitoring of industrial analog signals.
