Introduction

The Schneider 170ADO35000 DC Logic Output Base offers a reliable and efficient solution for controlling DC-powered output devices in industrial automation systems. Whether you are managing actuators, relays, or other digital output devices, the 170ADO35000 ensures precise control and smooth system performance. Designed for easy integration with Schneider Electric’s Modicon PLC systems, this module provides a compact, durable, and space-efficient option for expanding output capabilities in a wide variety of industrial applications.

Technical Specifications

Feature	Specification
Dimensions (L x W x H)	47.5 × 125 × 141.5 mm
Weight	0.21 kg (0.46 lb)
Output Type	DC Logic Output
Operating Temperature Range	-10°C to +60°C
Mounting	Standard DIN Rail Mountable
Protection Features	Surge protection, short-circuit protection
Compatible Systems	Schneider Electric Modicon PLCs

Applications

The Schneider 170ADO35000 DC Logic Output Base is designed for use in industrial automation systems to provide reliable digital output control. This module is ideal for controlling DC-powered actuators, relays, solenoids, and other output devices in environments that require precise and efficient digital logic control. It is widely used in sectors such as manufacturing, material handling, process control, and packaging, where fast and secure control of output devices is critical to system performance.

Advantages

Efficient DC Logic Control: The 170ADO35000 ensures precise and reliable control of DC-powered devices, delivering stable outputs for critical industrial processes.
Compact and Lightweight: With compact dimensions of 47.5 × 125 × 141.5 mm and a weight of just 0.21 kg (0.46 lb), this output base offers a space-saving solution for your automation systems while maintaining high performance.
Easy Integration: Designed to integrate seamlessly with Schneider Electric’s Modicon PLCs and other related automation products, the 170ADO35000 enhances the overall functionality of your control systems.
Durable Construction: Built to withstand industrial conditions, this output base is designed to operate in environments subject to electrical surges, temperature fluctuations, and mechanical stresses.
High Reliability: The module ensures continuous, reliable output performance, ensuring smooth operation of your automation system without interruptions.
Versatile Applications: The 170ADO35000 is suitable for a wide range of applications requiring DC logic output control, including relay and solenoid control, motor start/stop logic, and other similar uses.

Technical FAQs

What is the purpose of the Schneider 170ADO35000 DC Logic Output Base?
The 170ADO35000 is designed to control DC-powered output devices such as solenoids, relays, and actuators, providing reliable and precise logic outputs for industrial automation systems.
What is the weight of the Schneider 170ADO35000 DC Logic Output Base?
The output base weighs 0.21 kg (0.46 lb), offering a lightweight and space-efficient solution for automation systems.
How is the 170ADO35000 mounted?
The module is designed for easy mounting onto standard industrial backplates or mounting rails, ensuring secure installation within control panels.
Can the 170ADO35000 be used with other PLCs apart from Schneider’s Modicon series?
While designed for Schneider Electric’s Modicon PLC systems, the module may also be compatible with other PLC systems that support similar I/O configurations and communication protocols.
What types of output devices can be controlled using the 170ADO35000?
This module can control a variety of DC output devices, including relays, solenoids, motor control systems, and other actuators that require DC logic output signals.
What is the operating temperature range for the 170ADO35000?
The output base operates effectively within a temperature range of -10°C to +60°C, making it suitable for a wide range of industrial environments.
How does the 170ADO35000 integrate with Schneider PLC systems?
The module integrates seamlessly with Schneider Electric’s Modicon PLCs, allowing for quick and easy expansion of digital output capabilities within your automation system.
What kind of protection does the 170ADO35000 provide?
The 170ADO35000 features surge protection and other built-in safeguards to ensure reliable operation in demanding industrial environments, protecting against electrical disturbances.
Can the 170ADO35000 be used in hazardous environments?
While the module is robust and built for industrial use, it should be housed in an appropriate enclosure when used in hazardous or extreme environments to ensure safety and compliance.
Is the 170ADO35000 suitable for high-speed applications?
Yes, the module is designed to handle fast switching of DC output devices, ensuring quick response times for critical operations in real-time industrial applications.
