Introduction

The Schneider 170NEF11021 Modbus Plus Communication Adapter provides a reliable and high-performance solution for enabling communication between Schneider Electric’s Modicon PLCs and devices on a Modbus Plus network. With its fast data transmission capabilities and seamless integration into existing automation systems, this adapter helps improve the efficiency and performance of industrial operations. Whether used for real-time process control or data monitoring, the 170NEF11021 ensures reliable and continuous communication across the network, making it an essential component for modern industrial automation systems.

Technical Specifications

Feature	Specification
Dimensions (L x W x H)	58 × 180 × 259 mm
Weight	0.193 kg (0.43 lb)
Communication Protocol	Modbus Plus
Data Transfer Rate	Up to 10 Mbps
Mounting	DIN Rail Mountable
Operating Temperature Range	-10°C to +60°C
Protection Features	Industrial-grade protection for stable communication

Applications

The Schneider 170NEF11021 Modbus Plus Communication Adapter enables seamless communication between Schneider Electric’s Modicon PLCs and Modbus Plus network devices. This versatile adapter is ideal for industrial automation systems where communication between PLCs and a wide variety of field devices—such as sensors, actuators, and other control systems—is essential. It is commonly used in industries such as manufacturing, process control, energy management, and building automation. By offering robust and high-speed communication, this adapter enhances the interoperability of devices and optimizes system performance in real-time control and monitoring applications.

Advantages

Efficient Modbus Plus Communication: The 170NEF11021 ensures fast and reliable communication between Modicon PLCs and Modbus Plus-compatible devices, enabling efficient data exchange across industrial networks.
Compact and Lightweight: With dimensions of 58 × 180 × 259 mm and a weight of just 0.193 kg (0.43 lb), this adapter provides a space-saving solution without compromising on performance.
Seamless Integration: The adapter integrates effortlessly with Schneider Electric Modicon PLCs and other Modbus Plus-compatible devices, allowing for easy system expansion and upgrades.
High-Speed Data Transfer: Modbus Plus enables data transmission rates of up to 10 Mbps, ensuring real-time communication between devices for faster process control and monitoring.
Durable and Reliable: Built to withstand industrial environments, the 170NEF11021 is designed to offer long-lasting, reliable performance in harsh conditions, making it ideal for demanding automation systems.
Flexible Network Compatibility: This adapter supports a wide range of Modbus Plus devices, offering flexibility in connecting various field devices across the network.

Technical FAQs

What is the purpose of the Schneider 170NEF11021 Modbus Plus Communication Adapter?
The 170NEF11021 enables communication between Schneider Electric’s Modicon PLCs and devices on a Modbus Plus network, facilitating fast and reliable data exchange in industrial automation systems.
What is the weight of the Schneider 170NEF11021?
The adapter weighs 0.193 kg (0.43 lb), making it a lightweight and space-efficient solution for integration into your control system.
How is the 170NEF11021 installed?
The Modbus Plus Communication Adapter can be mounted easily on standard DIN rails, allowing for a secure and straightforward installation process within control panels.
Can the 170NEF11021 be used with other PLC systems apart from Schneider’s Modicon series?
While the 170NEF11021 is optimized for Schneider Electric Modicon PLCs, it can also work with any Modbus Plus-compatible system, offering flexibility for integration into various automation environments.
What devices can the 170NEF11021 communicate with?
The adapter communicates with a broad range of Modbus Plus-compatible field devices, including sensors, actuators, variable frequency drives (VFDs), and other industrial automation equipment.
What is the operating temperature range of the 170NEF11021?
The adapter operates within a temperature range of -10°C to +60°C, making it suitable for diverse industrial environments.
How fast is the data transfer over the Modbus Plus network?
The Modbus Plus protocol supports data transmission speeds of up to 10 Mbps, enabling fast, real-time communication between devices for critical industrial processes.
Does the 170NEF11021 support redundancy?
The 170NEF11021 itself does not provide inherent redundancy, but it can be integrated into systems that use Modbus Plus’s redundancy features to ensure continuous communication in mission-critical applications.
Is the 170NEF11021 suitable for use in hazardous environments?
While the adapter is robust for industrial use, it should be housed in an appropriate enclosure when used in hazardous or extreme environments to ensure safety and compliance with industry standards.
How does the 170NEF11021 improve system performance?
By enabling fast, efficient communication across a Modbus Plus network, the adapter improves system performance, allowing for quicker data exchange and real-time control of automation processes.
