Introduction

The Schneider TSXAEY810 Analog Input Module is a key component for integrating analog sensors and devices into Schneider Electric’s Modicon PLC systems. Whether used for voltage, current, or other analog signals, this module ensures precise data acquisition and seamless integration into your automation system. With its compact design and industrial durability, the TSXAEY810 is an ideal solution for applications that require high-accuracy analog-to-digital conversion and flexible integration into various industrial processes.

Technical Specifications

Feature	Specification
Dimensions (L x W x H)	55 × 180 × 260 mm
Weight	0.31 kg (0.68 lb)
Input Types	Voltage, Current
Operating Temperature Range	-10°C to +60°C
Mounting	Compatible with Modicon PLCs
Signal Processing	High-precision analog-to-digital conversion

Applications

The Schneider TSXAEY810 Analog Input Module is designed to expand the capabilities of Schneider Electric's Modicon PLC systems by providing high-precision analog signal acquisition. It is ideal for applications in industries such as manufacturing, process control, and automation, where accurate data from sensors and other analog devices is crucial. The module supports multiple types of analog input signals, including voltage and current, allowing it to interface with a wide variety of industrial equipment. Whether used in machine control, environmental monitoring, or process optimization, the TSXAEY810 ensures seamless and reliable integration of analog inputs into automation systems.

Advantages

Compact and Efficient: With dimensions of 55 × 180 × 260 mm and a weight of just 0.31 kg (0.68 lb), the TSXAEY810 offers a space-efficient solution for adding analog input capabilities to your Modicon PLC system without sacrificing performance.
High-Precision Signal Processing: This module offers high-accuracy analog-to-digital conversion, ensuring precise measurement and data acquisition for critical applications in industrial automation systems.
Wide Input Range: The TSXAEY810 is designed to handle a broad range of input signals, including both voltage and current types, making it versatile for various sensor interfaces and applications.
Seamless Integration: It integrates smoothly with Schneider Electric’s Modicon PLCs, enhancing your automation setup with easy installation and minimal configuration. It works with EcoStruxure Machine Expert for straightforward programming and diagnostics.
Industrial Durability: Built to withstand industrial environments, the TSXAEY810 module operates reliably across a wide temperature range of -10°C to +60°C, ensuring robust performance in diverse conditions.
Cost-Effective Solution: The TSXAEY810 provides high-performance analog input functionality at a competitive price point, delivering excellent value for users looking to integrate analog signal processing into their automation systems.

Technical FAQs

What is the purpose of the Schneider TSXAEY810 Analog Input Module?
The TSXAEY810 module is used to acquire and process analog input signals, converting them into digital values that can be used by Schneider Electric's Modicon PLC systems for control and monitoring applications.
What is the weight of the Schneider TSXAEY810?
The TSXAEY810 weighs 0.31 kg (0.68 lb), providing a compact and lightweight solution for expanding your Modicon PLC’s analog input capabilities.
What types of signals can the TSXAEY810 handle?
The module supports both voltage and current input signals, offering flexibility to interface with a wide range of analog sensors and devices in industrial applications.
How is the TSXAEY810 configured and programmed?
The TSXAEY810 can be configured and programmed using Schneider Electric’s EcoStruxure Machine Expert software, providing a user-friendly interface for setup, diagnostics, and system management.
What is the operating temperature range of the TSXAEY810?
The TSXAEY810 operates in a temperature range of -10°C to +60°C, making it suitable for use in a wide variety of industrial environments, from factory floors to more extreme conditions.
What industries can benefit from the TSXAEY810?
Industries such as manufacturing, process automation, robotics, and environmental control can benefit from the TSXAEY810’s ability to provide precise and reliable analog signal processing for critical systems.
Can the TSXAEY810 be integrated with other Schneider Electric modules?
Yes, the TSXAEY810 is designed to integrate seamlessly with Schneider Electric’s Modicon PLCs and other Schneider Electric automation products, allowing for a flexible and scalable system configuration.
How does the TSXAEY810 improve system performance?
The TSXAEY810 ensures high-precision data acquisition from analog devices, improving the accuracy and reliability of system control and monitoring functions, which is essential for process optimization and quality control.
How does the TSXAEY810 support system scalability?
The TSXAEY810 can be used as part of a modular system, allowing users to expand the number of analog inputs in their automation system as needed without requiring a complete redesign of the control architecture.
What is the key benefit of using the TSXAEY810 in automation systems?
The TSXAEY810 provides accurate, reliable analog signal processing at an affordable price, enhancing the flexibility and performance of Modicon PLC systems in a wide range of industrial automation applications.
