The GE DS200DTBAG1AAA is a Digital Contact Input Termination Module used in the GE Mark V Speedtronic turbine control system. It is designed to provide a structured and reliable interface between field-installed digital devices and the turbine control system, ensuring accurate signal collection, termination, and distribution.
This module plays a foundational role in turbine automation architecture by enabling clean signal routing, stable input processing, and safe electrical interfacing, especially in high-density control cabinet environments.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200DTBAG1AAA |
| Series | Mark V Speedtronic |
| Product Type | Digital Contact Input Termination Board |
| Functional Acronym | DTBA |
| Function | Digital signal termination & input routing |
| Terminal Blocks | 2 blocks supporting up to ~95 wires each |
| Maximum Wiring Capacity | Up to ~190 total connections |
| Connectors | J12, JQR, JQS/T, JY interface connectors |
| Jumpers | 5 configurable hardware jumpers |
| Input Voltage Range | 24–125 VDC |
| System Compatibility | GE Mark V turbine control system |
| Signal Type | Digital contact input signals |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8 kg |
| Mounting Type | Rack-mounted termination board |
Its compact yet high-density design allows efficient integration into complex turbine control panels.
