The ABB Bailey NMMU01 Network 90 Module Mounting Unit is a structural rack and chassis component designed for the ABB Bailey INFI 90 / Net 90 Distributed Control System (DCS). It provides the physical mounting framework for Network 90 modules, ensuring stable installation, precise alignment, and secure electrical connectivity within industrial control cabinets.
Unlike functional processing modules, the NMMU01 serves as the backbone of system architecture—supporting module organization, simplifying maintenance, and enabling scalable expansion of Bailey control systems. In large industrial environments, this mounting unit is essential for keeping complex DCS configurations organized, accessible, and operationally stable.
Its rugged industrial design ensures long-term reliability in demanding environments such as power generation and petrochemical facilities.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Type | Module Mounting Unit / Rack Chassis |
| System Compatibility | ABB Bailey Net 90 / INFI 90 |
| Main Function | Mechanical mounting and module housing |
| Slot Capacity | Up to 8–12 slots (system dependent) |
| Power Handling | Approx. 140 VA system support |
| Structure | Industrial rack chassis design |
| Installation | Cabinet-mounted system rack |
| Cooling Method | Natural convection |
| Operating Environment | Industrial automation systems |
| Operating Duty | Continuous 24/7 operation |
The NMMU01 is widely used as a structural foundation for Bailey Net 90 module assemblies, ensuring stable physical integration and system expansion capability.
Physical Dimensions & Weight
| Specification | Value |
|---|---|
| Dimensions (H × W × D) | 508 mm × 178 mm × 330 mm |
| Weight | ~3.2 kg |
Its robust steel-frame structure is designed to support multiple control modules while maintaining vibration resistance and installation stability in industrial environments.
Recommended Related Models
- ABB Bailey NMFP01 Multi-Function Processor Module
- ABB Bailey NMFC02 Multi-Function Controller Module
- ABB Bailey NICS01 Communication Slave Module
- ABB Bailey NIMP01 Processor Module
- ABB Bailey NTMP01 Processor Termination Unit
These components are typically installed within the NMMU01 chassis to build complete ABB Bailey control racks.
Popular ABB Bailey Models
- NMMU01 Network 90 Module Mounting Unit
- NMFP01 Processor Module
- NMFC02 Controller Module
- NICS01 Communication Module
- IMASI23 Analog Input Module
These ABB Bailey products are widely used in long-life industrial automation systems requiring structured module organization and reliable DCS operation.
