Introduction

The Allen Bradley 1746-NI16V Analog Input Module delivers precise voltage signal monitoring for industrial automation. Its compact and lightweight design allows easy integration into panels or DIN rails, while its robust construction ensures reliable operation in demanding environments. Fully compatible with Allen-Bradley SLC 500 PLCs, it provides accurate voltage measurement from sensors and devices, making it ideal for process control, manufacturing, and machinery automation applications.

Technical Specifications

Parameter	Specification
Module Type	Analog Input Module
Dimensions (L×W×H)	144.5 × 34.6 × 130.18 mm
Weight	0.38 kg / 0.84 lb
Input Type	Analog Voltage Signals (0–10 V)
Channels	16 input points
Operating Temperature	0°C to 60 °C
Storage Temperature	-20°C to 70 °C
Mounting	Panel / DIN Rail
Compatibility	Allen-Bradley SLC 500 PLCs

Applications

The Allen Bradley 1746-NI16V Analog Input Module is engineered for precise voltage signal monitoring in industrial automation systems. Ideal for process control, manufacturing equipment, and machinery automation, it allows SLC 500 PLCs to acquire real-time analog voltage data from sensors and field devices, enabling accurate monitoring and responsive control.

Advantages

High-Precision Voltage Inputs: Supports accurate acquisition of voltage signals for critical automation tasks.
Compact & Lightweight: 144.5 × 34.6 × 130.18 mm and 0.38 kg / 0.84 lb for convenient panel or DIN rail installation.
Industrial-Grade Reliability: Designed to perform consistently in demanding environments.
Seamless SLC 500 Integration: Fully compatible with Allen-Bradley SLC 500 PLCs.
Optimized Rack Space: Handles multiple analog voltage inputs in a single module, maximizing system efficiency.

Technical FAQs

How many analog input channels does the module support?
16 analog voltage input channels.
What voltage signal range is supported?
0–10 V voltage input signals.
Can it handle fast-changing analog signals?
Yes, optimized for real-time voltage signal acquisition.
Is it suitable for continuous industrial operation?
Yes, reliable operation from 0–60 °C.
Does it provide diagnostic feedback?
Yes, channel status and fault information are accessible through the SLC 500 PLC.
Can all channels operate simultaneously?
Yes, all 16 analog channels function independently.
Is panel or DIN rail mounting supported?
Yes, compact design allows flexible installation.
Does it require additional software or firmware?
No, fully managed through the SLC 500 PLC system.
What is the expected operational lifespan?
Over 10 years of reliable industrial performance.
Is it suitable for time-sensitive process control tasks?
Yes, it provides accurate and reliable analog voltage signal acquisition for responsive automation.
