Introduction

The Allen Bradley 1746-NO4I SLC 500 Analog Output Module provides reliable and accurate analog signal outputs for industrial control systems. It enables precise control of actuators, valves, and other field devices, ensuring smooth operation and process stability. Designed for industrial durability, the NO4I integrates seamlessly into SLC 500 systems and supports diagnostics, simple maintenance, and high signal fidelity, making it an essential component for automation and process control applications.

Technical Specifications

Parameter	Specification
Module Type	Analog Output Module
Model Number	1746-NO4I
Dimensions (L×W×H)	144.5 × 34.6 × 130.19 mm
Weight	0.18 kg / 0.40 lb
Functionality	Provides analog voltage or current outputs for SLC 500 systems
Channels	Multiple analog output channels
Signal Types	Voltage and current
Mounting	Allen Bradley SLC 500 Rack
Operating Temperature	0°C to 55 °C
Storage Temperature	-20°C to 70 °C
Compatibility	Allen Bradley SLC 500 Controllers & I/O modules

Applications

The Allen Bradley 1746-NO4I Analog Output Module is designed to provide precise analog signal outputs for SLC 500 systems. It is widely used in industrial automation, process control, and utility operations to regulate actuators, valves, and other analog-controlled devices. This module is ideal for applications where accurate analog output signals are critical for maintaining system performance and process stability.

Advantages

Precise Signal Output: Delivers accurate voltage or current analog outputs for control devices.
Compact Industrial Design: 144.5 × 34.6 × 130.19 mm and 0.18 kg / 0.40 lb, optimized for SLC 500 rack integration.
Reliable Operation: Industrial-grade components ensure consistent performance in harsh environments.
Easy Installation and Maintenance: Modular design simplifies wiring, replacement, and troubleshooting.
Seamless Integration: Fully compatible with Allen Bradley SLC 500 controllers and I/O modules.

Technical FAQs

What is the primary function of 1746-NO4I?
To provide precise analog outputs for control of actuators and devices in SLC 500 systems.
What signal types are supported?
Voltage and current analog outputs.
Can it handle multiple output channels?
Yes, it supports multiple analog output channels depending on configuration.
Is it suitable for industrial environments?
Yes, designed to withstand vibration, temperature changes, and electrical interference.
Does it require programming?
Minimal setup is required through the SLC 500 controller software.
Can it be used alongside analog input modules?
Yes, it integrates seamlessly with 1746-NI and NIO modules.
Does it support diagnostics?
Yes, provides output status monitoring and fault detection.
Can it improve process control accuracy?
Absolutely, precise analog output ensures accurate control of process devices.
Is maintenance complicated?
No, the modular design allows for easy inspection, replacement, and testing.
Can it be installed in standard SLC 500 racks?
Yes, the compact form factor is designed for standard SLC 500 mounting.
