Introduction

The Allen Bradley 1746-NT8 Thermocouple/mV Analog Input Module provides high-accuracy multi-channel acquisition of thermocouple and millivolt signals for SLC 500 systems. It captures critical thermal process data and transmits it reliably to the CPU for control and monitoring. The NT8 module’s industrial-grade design ensures consistent operation in challenging conditions, while its compact form factor simplifies integration, calibration, and maintenance. It is the ideal choice for applications where precise, multi-channel analog temperature measurement is essential.

Technical Specifications

Parameter	Specification
Module Type	Thermocouple/mV Analog Input Module
Model Number	1746-NT8
Dimensions (L×W×H)	144.5 × 34.6 × 130.18 mm
Weight	0.181 kg / 0.40 lb
Functionality	Multi-channel thermocouple and mV signal acquisition for SLC 500 systems
Channels	Typically 8 thermocouple/mV inputs
Signal Types	Thermocouple, millivolt
Mounting	Allen Bradley SLC 500 Rack
Operating Temperature	0°C to 55 °C
Storage Temperature	-20°C to 70 °C
Compatibility	Allen Bradley SLC 500 Controllers & I/O modules

Applications

The Allen Bradley 1746-NT8 Analog Input Module is designed for high-precision acquisition of thermocouple and millivolt signals within SLC 500 systems. It is ideal for industrial temperature monitoring, thermal process automation, and utility applications where multiple channels of thermal data are needed. Its reliability and accuracy make it suitable for chemical plants, power generation, and manufacturing environments.

Advantages

Multi-Channel Capability: Supports multiple thermocouple and mV input channels, reducing the need for additional modules.
Compact and Lightweight: 144.5 × 34.6 × 130.18 mm and 0.181 kg / 0.40 lb, designed for standard SLC 500 rack installations.
Industrial-Grade Reliability: Designed to resist vibration, electrical noise, and temperature variations.
Seamless Integration: Works directly with SLC 500 controllers and other I/O modules.
Maintenance-Friendly: Terminal-based design allows quick calibration, wiring, and replacement.

Technical FAQs

What types of signals does the 1746-NT8 handle?
Thermocouple and millivolt signals from industrial sensors.
How many input channels are supported?
Multiple channels, typically 8 for thermocouple/mV inputs.
Is it suitable for harsh industrial environments?
Yes, it withstands vibration, temperature swings, and electrical interference.
Does it require configuration?
Minimal setup is required through SLC 500 programming software.
Can it replace multiple single-channel modules?
Yes, the NT8 consolidates multiple thermocouple/mV channels into one module.
Does it support diagnostics?
Yes, it monitors signal integrity and provides error detection.
Can it improve process control accuracy?
Absolutely, precise thermocouple and millivolt acquisition enhances control reliability.
Is calibration supported?
Yes, it allows calibration for accurate temperature and voltage measurements.
Can it integrate with other SLC 500 analog modules?
Yes, fully compatible with analog input, output, and combined I/O modules.
Which industries benefit most from this module?
Industries requiring precise temperature monitoring, including chemical, food & beverage, and energy sectors.
