Introduction

The Allen Bradley 1746-OV16 Digital Output Module delivers 16-channel digital output for SLC 500 systems, offering precise and reliable control of relays, solenoids, and other DC-powered devices. Its compact and lightweight design ensures easy installation and handling, while its industrial-grade construction guarantees dependable performance in demanding environments. Fully compatible with SLC 500 CPUs and I/O modules, the OV16 module simplifies system wiring, enhances operational efficiency, and provides diagnostic capabilities for maintenance and monitoring.

Technical Specifications

Parameter	Specification
Module Type	Digital Output Module
Model Number	1746-OV16
Dimensions (L×W×H)	144.5 × 34.6 × 130.18 mm
Weight	0.16 kg / 0.35 lb
Functionality	16-channel digital output for SLC 500 systems
Channels	16 digital output channels
Output Type	DC
Mounting	Allen Bradley SLC 500 Rack
Operating Temperature	0°C to 55 °C
Storage Temperature	-20°C to 70 °C
Compatibility	Allen Bradley SLC 500 Controllers & I/O modules

Applications

The Allen Bradley 1746-OV16 Digital Output Module provides reliable digital control for SLC 500 systems. It is ideal for industrial automation, manufacturing, and process control applications, driving relays, solenoids, indicator lights, and other DC-powered devices. With 16 output channels, it efficiently manages medium-scale systems that require precise digital output control.

Advantages

16 Independent Channels: Centralized control for multiple devices with high reliability.
Lightweight Design: 144.5 × 34.6 × 130.18 mm, weighing 0.16 kg / 0.35 lb, allowing for easy handling and installation.
Industrial Durability: Designed to perform consistently in harsh industrial conditions, including vibration and electrical noise.
Seamless Integration: Fully compatible with SLC 500 CPUs and other I/O modules.
Maintenance Friendly: Terminal-based design ensures quick installation, inspection, and replacement.

Technical FAQs

How many output channels does the 1746-OV16 support?
16 independent digital output channels.
What types of devices can it drive?
Relays, solenoids, indicator lights, and other digital-controlled devices.
Is it suitable for industrial environments?
Yes, it is engineered to withstand vibration, electrical noise, and temperature fluctuations.
What is the standard output voltage?
Compatible with standard 24V DC industrial control circuits.
Does it provide diagnostic feedback?
Yes, it supports channel status monitoring and fault detection.
Is programming required?
Minimal configuration is needed through SLC 500 CPU programming software.
Can it consolidate outputs from multiple smaller modules?
Yes, its 16 channels allow for efficient consolidation of outputs.
What is the switching speed?
Optimized for rapid on/off operation in industrial automation systems.
Is maintenance straightforward?
Yes, modular design allows easy inspection and quick replacement.
Is it compatible with standard SLC 500 racks?
Yes, fully compatible with standard SLC 500 rack configurations.
