The Allen Bradley 2097-F2 is a line filter designed for use with Kinetix 350 EtherNet/IP servo drive systems. It is used to reduce electromagnetic interference (EMI) and radio-frequency interference (RFI) generated by servo drives, helping industrial systems meet EMC compliance requirements and improving overall electrical noise immunity.
The filter is typically installed between the incoming AC power source and the Kinetix servo drive to minimize conducted electrical noise in industrial automation environments.
Typical applications include:
- Servo motion systems
- Packaging machinery
- CNC equipment
- Robotics systems
- Material handling equipment
- Automated assembly systems
- Precision positioning applications
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 2097-F2 |
| Product Family | Kinetix 350 Accessories |
| Product Type | EMI/RFI Line Filter |
| Compatible Drives | Kinetix 350 Servo Drives |
| Input Voltage | 120/240V AC |
| Phase Type | Single-phase |
| Frequency | 50/60 Hz |
| Current Rating | Approx. 9–12 A class |
| Function | EMI/RFI noise suppression |
| Installation Location | AC input side of servo drive |
| Mounting Type | Panel mount |
| Cooling Method | Passive |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to 50°C |
Physical Dimensions & Weight (L × W × H)
| Parameter | Specification |
|---|---|
| Dimensions | Approx. 180 × 70 × 50 mm |
| Weight | Approx. 0.8–1.2 kg |
Main Functions
The 2097-F2 line filter provides:
- EMI suppression
- RFI reduction
- Improved electrical noise immunity
- Enhanced system stability
- EMC compliance support
- Reduced conducted emissions to the power line
Typical installation:
AC Power → 2097-F2 Line Filter → Kinetix 350 Drive → Servo Motor
Recommended Related Models
| Model | Description |
|---|---|
| 2097-V31PR0 | Kinetix 350 Servo Drive |
| 2097-V32PR2 | Kinetix 350 Servo Drive |
| 2090 Series | Motor power and feedback cables |
| MPL / VPL Motors | Compatible servo motors |
| 2198 Series | Kinetix 5500/5700 replacement systems |
| 1606-XLE Series | Industrial power supplies |
| 1734-AENTR | POINT I/O adapter |
| 5069-L320ER | CompactLogix controller |
