The Allen Bradley 2711P-T7C22D8S PanelView Plus 7 Standard Terminal is a modern industrial HMI (Human-Machine Interface) designed for high-speed visualization, machine control, and real-time operator interaction. Built within Rockwell Automation’s PanelView Plus 7 platform, it delivers reliable communication with CompactLogix and ControlLogix PLC systems, making it a core interface solution for smart factory environments.
Engineered for durability and responsiveness, this model is widely adopted in production lines where clear data visualization, network stability, and operator efficiency directly impact manufacturing output.
Technical Specifications
| Category | Specification |
|---|---|
| Product Family | PanelView Plus 7 Standard |
| Model Number | 2711P-T7C22D8S |
| Display Type | TFT active-matrix color LCD |
| Screen Size | 6.5 inches |
| Resolution | 640 × 480 (VGA) |
| Aspect Ratio | 4:3 |
| Touch Type | Analog resistive touchscreen |
| Operating System | Windows CE 6.0 |
| Communication | 1–2× Ethernet, USB host |
| Input Voltage | 18–30 V DC (24V nominal) |
| Memory | 512 MB RAM / 512 MB storage |
| User Memory | ~80 MB application runtime space |
| Backlight Life | ~50,000 hours (LED) |
| Protection Rating | Industrial panel-mount rated (front IP66 typical) |
| Operating Temperature | 0°C to 55°C |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 152 mm × 176 mm × 56.5 mm |
| Weight | Approx. 1.2 kg |
Recommended Related Models
For system expansion or upgrade planning within the PanelView ecosystem, the following models are commonly used:
- Allen Bradley 2711P-T10C22D9P PanelView Plus 7 Performance
- Allen Bradley 2711P-T7C21D8S PanelView Plus 7 Standard variant
- Allen Bradley 2711P-T6C21D8S Compact HMI terminal
- Allen Bradley 1769-L33ER CompactLogix Controller
- Allen Bradley 1756-L85E ControlLogix CPU Module
These units ensure smooth integration across Rockwell’s PLC and HMI architecture.
Popular Allen Bradley PanelView Models
- 2711P-T7C22D8S PanelView Plus 7 Standard
- 2711P-T7C21D8S PanelView Plus 7 Standard
- 2711P-T10C4D8 PanelView Plus 7 Performance
- 2711P-T6C21D8S Compact HMI Terminal
- 2711P-T6M5A8 PanelView Plus 6 Legacy Unit
