Emerson VE4001S2T2B4 KJ3203X1-BA1 Analog Output Module
Emerson VE4001S2T2B4 KJ3203X1-BA1 Analog Output Module
0.0
Points
Brand:Emerson Module Item No.:Emerson VE4001S2T2B4 KJ3203X1-BA1 Product Origin:USA Product Dimensions:142 × 108 × 46 mm Product Weight:0.35 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson VE4001S2T2B4 (KJ3203X1-BA1) is a DeltaV Series 2 analog output module engineered to deliver accurate and reliable control signals to field devices across a wide range of industrial processes. Designed for seamless integration within DeltaV distributed control systems, this module provides stable analog output performance for control valves, actuators, variable frequency drives, and other final control elements.
Its robust design, advanced diagnostics, and high signal accuracy make it an excellent choice for facilities seeking enhanced process control, operational efficiency, and long-term system reliability.
Technical Specifications
Parameter
Specification
Manufacturer
Emerson
Model
VE4001S2T2B4 (KJ3203X1-BA1)
Product Type
Analog Output Module (AO)
System Platform
DeltaV Series 2
Output Channels
8 channels
Output Signal Type
4–20 mA
Output Resolution
16-bit
Signal Accuracy
High-precision industrial control
Isolation
Channel-to-system isolation
Diagnostics
Output channel monitoring and fault detection
Field Power Requirement
External field power supported
Mounting Method
DeltaV I/O carrier installation
Operating Temperature
-40°C to +70°C
Humidity Range
5% to 95% non-condensing
EMC Compliance
Industrial-grade noise immunity
Physical Dimensions & Weight
Parameter
Specification
Dimensions (L × W × H)
142 × 108 × 46 mm
Weight
Approx. 0.35 kg
Compatible and Recommended Modules
For complete DeltaV system deployment, the VE4001S2T2B4 is frequently installed together with:
Emerson VE3006 MD Plus Controller Module
Emerson VE3008 MQ Controller Module
Emerson VE4003S2B1 Analog Input Module
Emerson VE4005S2B1 Analog Output Module
Emerson VE4033S2B1 Redundant Input Module
Emerson VE4001S2T2B1 Discrete Input Module
Emerson SE4053S2B11 Analog Input Card
Emerson SE4055S2B5 Analog Output Card
These modules help create a highly scalable and dependable DeltaV automation infrastructure.
Popular Emerson DeltaV Modules
Some of the most widely used DeltaV modules include:
VE3006 MD Plus Controller
VE3008 MQ Controller
KJ3203X1-BA1 Analog Output Module
KJ3222X1-BA1 Discrete Input Module
KJ3241X1-BA1 Serial Interface Module
VE4033S2B1 Redundant I/O Module
VE4003S2B1 Analog Input Module
Typical Applications
Oil & Gas Facilities
Used to control flow valves, pressure regulators, and process control equipment in upstream and downstream operations.
Chemical Processing Plants
Provides precise analog control signals for reactors, dosing systems, and production processes requiring accurate output regulation.
Power Generation
Supports turbine control systems, boiler regulation, and auxiliary process automation.
Water and Wastewater Treatment
Delivers stable control signals for pumps, dosing equipment, and automated treatment processes.
Industrial Manufacturing
Enhances production efficiency through accurate control of drives, actuators, and automated machinery.
Key Advantages
High Output Accuracy
Delivers stable and precise analog signals that help maintain consistent process control.
Reliable DeltaV Integration
Designed specifically for Emerson DeltaV systems, ensuring straightforward configuration and dependable operation.
Robust Industrial Design
Built to withstand demanding industrial environments while maintaining long-term performance.
Enhanced Diagnostics
Supports continuous monitoring of output channels, reducing troubleshooting time and maintenance costs.
Compact Installation Footprint
Maximizes cabinet space utilization while providing high channel density.
Improved Process Efficiency
Helps optimize control accuracy, resulting in better product quality and reduced operational variability.
Technical FAQs
1. What is the primary function of the VE4001S2T2B4 KJ3203X1-BA1?
It generates analog control signals for field devices within a DeltaV automation system.
2. How many output channels are available?
The module provides 8 analog output channels.
3. What output signal does it support?
It supports industry-standard 4–20 mA analog output signals.
4. Can it be used with control valves?
Yes, it is commonly used to drive control valves and actuators.
5. Does the module support diagnostics?
Yes, built-in diagnostics help monitor channel health and output status.
6. What control system is it designed for?
It is designed for Emerson DeltaV Series 2 distributed control systems.
7. Is the module suitable for continuous operation?
Yes, it is engineered for 24/7 industrial process applications.
8. What industries commonly use this module?
Oil & gas, chemical processing, power generation, water treatment, and manufacturing.
9. What are the physical dimensions?
The dimensions are approximately 142 × 108 × 46 mm (L × W × H).
10. What is the module weight?
The weight is approximately 0.35 kg, making it compact and easy to integrate into control cabinets.
